Imaging | Lens Mount | Canon EF |
|---|
| Camera Format | APS-C (1.6x Crop Factor) |
|---|
| Pixels | Actual: 24.7 Megapixel
Effective: 24.1 Megapixel |
|---|
| Max. Resolution | 6000 x 4000 |
|---|
| Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
|---|
| Sensor Type | CMOS |
|---|
| Sensor Size | 22.3 x 14.9 mm |
|---|
| Format | JPEG, Raw |
|---|
| Depth | 14-Bit |
|---|
| Stabilization | None |
|---|
Exposure Control | ISO | Auto, 100 to 6400 (Extended: 100 to 12800) |
|---|
| Shutter | 1/4000 to 30 Seconds
Bulb Mode |
|---|
| Metering Method | Center-Weighted Average, Evaluative, Partial |
|---|
| Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
|---|
| Exposure Compensation | -5 to +5 EV (1/3, 1/2 EV Steps) |
|---|
| Metering Range | 1 to 20 EV |
|---|
| White Balance | Auto, Cloudy, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten |
|---|
| Continuous Shooting | Up to 3 fps at 24 MP for up to 150 Frames (JPEG) / 11 Frames (Raw) |
|---|
| Self-Timer | 2/10-Second Delay |
|---|
Video | Recording Modes | MOV/H.264
Full HD (1920 x 1080) at 24.00p/25p/29.97p (46 Mb/s)
HD (1280 x 720) at 50p/59.94p (46 Mb/s)
SD (640 x 480) at 25p/29.97p (11 Mb/s) |
|---|
| External Recording | Full HD (1920 x 1080)
SD (640 x 480) |
|---|
| Rec Limit | Up to 29 Minutes, 59 Seconds for Full HD (1920 x 1080) |
|---|
| Video Encoding | NTSC/PAL |
|---|
| Audio Recording | Built-In Microphone (Stereo) |
|---|
| Audio File Format | Linear PCM |
|---|
Focus | Type | Auto and Manual Focus |
|---|
| Mode | Manual Focus (M), Single-Servo AF (S) |
|---|
| Autofocus Points | Phase Detection: 9 (1 Cross-Type) |
|---|
| Autofocus Sensitivity | 0 to +18 EV |
|---|
Viewfinder and Monitor | Viewfinder Type | Optical (Pentamirror) |
|---|
| Viewfinder Eye Point | 21 mm |
|---|
| Viewfinder Coverage | 95% |
|---|
| Viewfinder Magnification | Approx. 0.8x |
|---|
| Diopter Adjustment | -2.5 to +0.5 |
|---|
| Monitor Size | 3" |
|---|
| Monitor Resolution | 920,000 Dot |
|---|
| Monitor Type | Fixed LCD |
|---|
Flash | Built-In | + |
|---|
| Modes | Auto, Flash On, Off |
|---|
| Guide Number | 30.18' / 9.2 m at ISO 100 |
|---|
| Max. Sync Speed | 1/200 Second |
|---|
| Compensation | -2 to +2 EV (1/3, 1/2 EV Steps) |
|---|
| System | eTTL |
|---|
| External Connection | Hot Shoe |
|---|
Interface | Memory Card Slot | Single Slot: SD/SDHC/SDXC (UHS-I) |
|---|
| Connectivity | Canon E3, HDMI C (Mini), USB Micro-B (USB 2.0) |
|---|
| Wireless | Wi-Fi |
|---|
| GPS | - |
|---|
Environmental | Temperature | 32 to 104°F / 0 to 40°C |
|---|
| Humidity | 0 to 85% |
|---|
Physical | Battery | 1 x LP-E10 Rechargeable Lithium-Ion, 7.4 VDC, 860 mAh |
|---|
| WxHxD | 5.1 x 4 x 3.1" / 129 x 101.3 x 77.6 mm |
|---|
| Weight | 1.05 lb / 475 g (Body with Battery and Memory) |
|---|
Kit Lens | Focal | 18 to 55mm (35mm Equivalent Focal Length: 28.8 to 88mm) |
|---|
| Max Aperture | f/3.5 to 5.6 |
|---|
| Min Aperture | f/22 to 38 |
|---|
| Angle of View | 74° 20' to 27° 50' |
|---|
| Max. Magnification | 0.34x |
|---|
| Macro Reproduction Ratio | 1:2.94 |
|---|
| Min. Focus Distance | 9.84" / 25 cm |
|---|
| Optical | 11 Elements in 9 Groups |
|---|
| Diaphragm Blades | 6, Rounded |
|---|
| Focus Type | Autofocus |
|---|
| Image Stabilization | + |
|---|
| Filter Size | 58 mm (Front) |
|---|
| Dimensions (ø x L) | 2.7 x 2.8" / 68.5 x 71.1 mm |
|---|
| Weight | 7.09 oz / 201 g |
|---|
|
