Imaging | Lens Mount | Canon RF |
|---|
| Resolution | Actual: 25.5 Megapixel
Effective: 24.2 Megapixel |
|---|
| Sensor Type | 22.3 x 14.9 mm (APS-C) CMOS |
|---|
| Crop Factor | 1.6x |
|---|
| Stabilization | Digital (Video Only) |
|---|
| ND Filter | None |
|---|
| Capture Type | Stills & Video |
|---|
Exposure Control | Shutter Type | Electronic Shutter, Mechanical Focal Plane Shutter |
|---|
| Shutter | Mechanical Shutter
1/4000 to 30 Seconds
Electronic Shutter
1/4000 to 30 Seconds |
|---|
| Bulb | Bulb Mode |
|---|
| ISO | Photo
100 to 32,000 in Manual, Auto Mode (Extended: 100 to 51,200) |
|---|
| Metering Method | Center-Weighted Average, Evaluative, Partial, Spot |
|---|
| Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
|---|
| Exposure Compensation | -3 to +3 EV (1/3, 1/2 EV Steps) |
|---|
| Metering Range | -2 to 20 EV |
|---|
| White Balance | Presets: Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten |
|---|
| Continuous Shooting | Electronic Shutter
Up to 23 fps at 24.2 MP for up to 70 Frames (JPEG) / 21 Frames (Raw)
Mechanical Shutter
Up to 15 fps at 24.2 MP for up to 460 Frames (JPEG) / 29 Frames (Raw) |
|---|
| Interval Recording | + |
|---|
| Self-Timer | 2/10-Second Delay |
|---|
Image | Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
|---|
| Format | C-RAW, HEIF, JPEG, Raw |
|---|
Internal Video | Recording Modes | H.264/MP4 4:2:0 8-Bit
UHD 4K (3840 x 2160) at 23.98p/25p/29.97p/59.94p
Full HD (1920 x 1080) at 23.98p/25p/29.97p/50p/59.94p/100p/119.88p
H.265/MP4 4:2:2 10-Bit
UHD 4K (3840 x 2160) at 23.98p/25p/29.97p/50p/59.94p
Full HD (1920 x 1080) at 23.98p/25p/29.97p/50p/59.94p/100p/119.88p |
|---|
| Gamma Curve | HDR-PQ |
|---|
| Video System | NTSC/PAL |
|---|
| Microphone | Stereo |
|---|
| Audio Recording | MP4: 2-Channel AAC Audio |
|---|
External Video Capture Interface | Media | Single Slot: SD/SDHC/SDXC (UHS-II) |
|---|
| Video | 1 x Micro-HDMI Output |
|---|
| Audio | 1 x 1/8" / 3.5 mm TRS Stereo Microphone Output |
|---|
| Other | 1 x USB Type-C (USB 2.0) Input/Output |
|---|
| Wireless | 2.4 GHz Wi-Fi (802.11b/g)
Bluetooth |
|---|
| GPS | None |
|---|
Monitor | Size | 3.0" |
|---|
| Resolution | 1,040,000 Dot |
|---|
| Display | Free-Angle Tilting Touchscreen LCD |
|---|
Viewfinder | Type | Built-In Electronic (OLED) |
|---|
| Resolution | 2,360,000 Dot |
|---|
| Eye Point | 22 mm |
|---|
| Coverage | 100% |
|---|
| Magnification | Approx. 0.95x |
|---|
| Diopter Adjustment | -3 to +1 |
|---|
Focus | Type | Auto and Manual Focus |
|---|
| Mode | Continuous-Servo AF, Manual Focus, Single-Servo AF |
|---|
| Autofocus Points | Photo, Video
Phase Detection: 651 |
|---|
| Autofocus Sensitivity | -4 to +20 EV |
|---|
Flash | Built-In | + |
|---|
| Guide Number | 19.7' / 6 m at ISO 100 |
|---|
| Max. Sync Speed | 1/250 Second |
|---|
| Compensation | -3 to +3 EV (1/3, 1/2 EV Steps) |
|---|
| System | eTTL |
|---|
| External Connection | Hot Shoe |
|---|
Environmental | Temperature | 32 to 104°F / 0 to 40°C |
|---|
| Humidity | 0 to 85% |
|---|
General | Battery | 1 x LP-E17 Rechargeable Lithium-Ion |
|---|
| Tripod Mounting | 1 x 1/4"-20 Female (Bottom) |
|---|
| WxHxD | 4.8 x 3.5 x 3.3" / 122.5 x 87.8 x 83.4 mm |
|---|
| Weight | 13.5 oz / 382.2 g (Body Only)
15.1 oz / 429.2 g (With Battery, Recording Media) |
|---|
Kit Lens | Focal | 18 to 150mm (35mm Equivalent Focal Length: 28.8 to 240mm) |
|---|
| Max Aperture | f/3.5 to 6.3 |
|---|
| Min Aperture | f/40 |
|---|
| Angle of View | 74° 20' to 10° 25' |
|---|
| Max. Magnification | 0.44x |
|---|
| Min. Focus Distance | 6.7" / 17 cm |
|---|
| Optical | 17 Elements in 13 Groups |
|---|
| Diaphragm Blades | 7 |
|---|
| Focus Type | Autofocus |
|---|
| Image Stabilization | + |
|---|
| Filter Size | 55 mm (Front) |
|---|
| Dimensions (ø x L) | 2.7 x 5" / 69 x 126.7 mm |
|---|
| Weight | 10.9 oz / 310 g |
|---|
Packaging | Weight | 2.89 lb / 1.31 kg |
|---|
| Box LxWxH | 11.4 x 7.8 x 6" |
|---|
|
