Imaging | Lens Mount | Canon RF |
|---|
| Resolution | Actual: 25.6 Megapixel
Effective: 24.2 Megapixel (6000 x 4000) |
|---|
| Sensor Type | 35.9 x 23.9 mm (Full-Frame) CMOS |
|---|
| Stabilization | Sensor-Shift, 5-Axis |
|---|
| ND Filter | - |
|---|
| Capture Type | Stills & Video |
|---|
Exposure Control | Shutter Type | Electronic Shutter, Mechanical Focal Plane Shutter |
|---|
| Shutter | Mechanical Shutter
1/8000 to 30 Seconds
Electronic Shutter
1/16000 to 30 Seconds |
|---|
| Bulb | Bulb Mode |
|---|
| ISO | 100 to 102,400 in Manual, Auto Mode (Extended: 50 to 204,800) |
|---|
| Metering Method | Center-Weighted Average, Evaluative, Partial, Spot |
|---|
| Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
|---|
| Exposure Compensation | -3 to +3 EV (1/3, 1/2 EV Steps) |
|---|
| Metering Range | -3 to 20 EV |
|---|
| White Balance | Presets: Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten |
|---|
| Continuous Shooting | Mechanical Shutter
Up to 12 fps at 24 MP for up to 1000 Frames (JPEG) / 110 Frames (Raw)
Electronic Shutter
Up to 40 fps at 24 MP for up to 190 Frames (JPEG) / 75 Frames (Raw) |
|---|
| Interval Recording | + |
|---|
| Self-Timer | 2/10-Second Delay |
|---|
Image | Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
|---|
| Format | C-RAW, HEIF, JPEG |
|---|
| Depth | 14-Bit |
|---|
Video | Internal Recording | H.264/H.265/MPEG-4 4:2:2 10-Bit
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94 fps (60 to 340 Mb/s)
1920 x 1080 at 23.98/25/29.97/50/59.94/100/119.88/150/179.82 fps (12 to 270 Mb/s) |
|---|
| External Rec | Raw via HDMI
6144 x 4032 up to 59.94 fps |
|---|
| Gamma Curve | Canon Log 3, HDR-PQ |
|---|
| Rec Limit | - |
|---|
| IP Streaming | + |
|---|
| Microphone | Stereo |
|---|
| Audio | LPCM Audio
AAC Audio |
|---|
Interface | Media | Dual Slot: SD/SDHC/SDXC (UHS-II) |
|---|
| Video | 1 x Micro-HDMI Output |
|---|
| Audio | 1 x 1/8" / 3.5 mm TRS Stereo Microphone Input on Camera Body
1 x 1/8" / 3.5 mm TRS Stereo Headphone Output on Camera Body |
|---|
| Power | 1 x USB-C Input |
|---|
| Other | 1 x USB-C (USB 3.2 / 3.1 Gen 2) Data/Tether Input/Output (Shared with Power Input) |
|---|
| Wireless | 2.4 / 5 GHz Wi-Fi 5 (802.11ac) Control
Bluetooth |
|---|
| App Compatible | No
*As of November, 2022 |
|---|
| GPS | - |
|---|
Monitor | Size | 3.0" |
|---|
| Resolution | 1,620,000 Dot |
|---|
| Display | Touchscreen LCD |
|---|
Viewfinder | Type | Built-In Electronic (OLED) |
|---|
| Size | 0.5" |
|---|
| Resolution | 3,690,000 Dot |
|---|
| Eye Point | 23 mm |
|---|
| Coverage | 100% |
|---|
| Magnification | Approx. 0.76x |
|---|
| Diopter Adjustment | -4 to +2 |
|---|
Focus | Type | Auto and Manual Focus |
|---|
| Mode | Continuous-Servo AF, Manual Focus, Single-Servo AF |
|---|
| Autofocus Points | Photo, Video
Contrast Detection, Phase Detection: 1053 |
|---|
| Autofocus Sensitivity | -6.5 to +21 EV |
|---|
Flash | Built-In | - |
|---|
| Max. Sync Speed | 1/250 Second |
|---|
| Compensation | -3 to +3 EV (1/3, 1/2 EV Steps) |
|---|
| System | eTTL |
|---|
| External Connection | Intelligent Hot Shoe |
|---|
General | Battery | 1 x LP-E6NH Rechargeable Lithium-Ion, 7.2 VDC, 2130 mAh (Approx. 760 Shots) |
|---|
| Tripod Mounting | 1 x 1/4"-20 Female (Bottom) |
|---|
| WxHxD | 5.4 x 3.9 x 3.5" / 138.4 x 98.4 x 88.4 mm |
|---|
| Weight | 1.3 lb / 588 g (With Battery, Recording Media) |
|---|
Packaging | Weight | 2.755 lb / 0.57 kg |
|---|
| Box LxWxH | 11 x 9.1 x 5" |
|---|
| Focal | 24 to 105mm |
|---|
| Max Aperture | f/4 to 7.1 |
|---|
| Min Aperture | f/40 |
|---|
| Lens Mount | Canon RF |
|---|
| Lens Format Coverage | Full-Frame |
|---|
| Angle of View | 84° to 23° 20' |
|---|
| Min. Focus Distance | 5.16" / 13.1 cm |
|---|
| Max. Magnification | 0.5x |
|---|
| Optical | 13 Elements in 11 Groups |
|---|
| Diaphragm Blades | 7, Rounded |
|---|
| Focus Type | Autofocus |
|---|
| Image Stabilization | + |
|---|
| Filter Size | 67 mm (Front) |
|---|
| Dimensions (ø x L) | 3.02 x 3.5" / 76.6 x 88.8 mm |
|---|
| Max. Extension | 5.45" / 138.4 mm |
|---|
| Weight | 13.93 oz / 395 g |
|---|
Info | Package | 1.255 lb / 0.57 kg |
|---|
| Box Dimensions | 7.6 x 4.9 x 4.7" |
|---|
|
