Image | Lens Mount | Micro Four Thirds |
|---|
| Resolution | Actual: 21.8 Megapixel
Effective: 20.3 Megapixel (5184 x 3888) |
|---|
| Sensor Type | 17.4 x 13 mm (Four Thirds) MOS |
|---|
| Crop Factor | 2x |
|---|
| Stabilisation | Sensor-Shift, 5-Axis |
|---|
| ND Filter | None |
|---|
| Capture Type | Stills & Video |
|---|
Exposure | Shutter Type | Mechanical Focal Plane Shutter, Electronic Shutter |
|---|
| Bulb/Time Mode | Bulb Mode, Time Mode |
|---|
| ISO Sensitivity | 200 to 25,600 in Auto Mode (Extended: 100 to 25,600) |
|---|
| Metering | Center-Weighted Average, Multi-Zone, Spot |
|---|
| Exposure | Aperture Priority, Auto, Manual, Program, Shutter Priority |
|---|
| Compensation | -5 to +5 EV (1/3, 1/2, 1 EV Steps) |
|---|
| Metering Range | -2 to 20 EV |
|---|
| WB | Presets: Auto, Colour Temperature |
|---|
| Interval Recording | Yes |
|---|
| Self Timer | 2/12-Second Delay |
|---|
Still Photography | Image Sizes | 4:3 Raw
5184 x 3888
4608 x 3456
4:3 JPEG
5184 x 3888
3200 x 2400
1280 x 960 |
|---|
| Aspect Ratio | 4:3 |
|---|
| Format | JPEG, Raw |
|---|
| Bit Depth | 12-Bit |
|---|
Internal Video Capture | Rec Limit | Up to 29 Minutes |
|---|
| Broadcast Output | NTSC/PAL |
|---|
| Built-In Microphone Type | Stereo |
|---|
| Audio | 2-Channel LPCM Audio |
|---|
External Video Capture | External Recording | HDMI
UHD 4K (3840 x 2160) up to 29.97p |
|---|
| IP Streaming | None |
|---|
Connectivity | Media | Single Slot: SD/SDHC/SDXC (UHS-II) |
|---|
| Video | 1 x Micro-HDMI Output |
|---|
| Audio | None |
|---|
| Power | 1 x USB Micro-B Input/Output |
|---|
| Other | 1 x USB Micro-B (USB 2.0) Input/Output (Shared with Power Input) |
|---|
| Wireless | Bluetooth, Wi-Fi |
|---|
| Satnav (GPS, GLONASS, etc.) | None |
|---|
Screen | Size | 3.0" |
|---|
| Resolution | 1,040,000 Dot |
|---|
| Screen Type | 180° Tilting Touchscreen LCD |
|---|
Viewfinder | Type | Built-In Electronic (OLED) |
|---|
| Resolution | 2,360,000 Dot |
|---|
| Eye Point | 19.2 mm |
|---|
| Coverage | 100% |
|---|
| Magnification | Approx. 0.67x |
|---|
| Diopter Adjustment | -4 to +2 |
|---|
Focus | Focusing | Auto and Manual Focus |
|---|
| Focus Modes | Continuous-Servo AF, Manual Focus, Single-Servo AF |
|---|
| AF Points | Contrast Detection: 121 |
|---|
Flash | Built-In | Yes |
|---|
| Guide Number | 16.73 / 5.1 m at ISO 100 |
|---|
| Max. Sync Speed | 1/250 Second |
|---|
| Flash Compensation | -3 to +3 EV (1/3, 1/2, 1 EV Steps) |
|---|
| Dedicated Flash System | TTL |
|---|
| External Connection | Hot Shoe |
|---|
Environmental | Operating Temperature | 14 to 104°F / -10 to 40°C |
|---|
| Storage Temperature | -4 to 140°F / -20 to 60°C |
|---|
| Operating Humidity | 30 to 90% |
|---|
| Storage Humidity | 10 to 90% |
|---|
General Information | Battery Type | 1 x BLS-50 Rechargeable Lithium-Ion, 7.2 VDC, 1175 mAh (Approx. 360 Shots) |
|---|
| Tripod Mounting Thread | 1 x 1/4"-20 Female (Bottom) |
|---|
| Accessory Mount | 1 x Hot Shoe Mount |
|---|
| WxHxD | 4.79 x 3.32 x 1.93" / 121.7 x 84.4 x 49 mm |
|---|
| Weight | 11.82 oz / 335 g (Body Only)
13.5 oz / 383 g (With Battery, Recording Media) |
|---|
Kit Lens | Focal | 14 to 42mm (35mm Equivalent Focal Length: 28 to 84mm) |
|---|
| Max Aperture | f/3.5 to 5.6 |
|---|
| Min Aperture | f/22 |
|---|
| Angle of View | 75° to 29° |
|---|
| Max. Magnification | 0.23x |
|---|
| Min. Focus Distance | 7.87" / 20 cm |
|---|
| Optical | 8 Elements in 7 Groups |
|---|
| Diaphragm Blades | 5, Rounded |
|---|
| Focus Type | Autofocus |
|---|
| Filter Size | 37 mm (Front) |
|---|
| Dimensions (ø x L) | 2.4 x 0.9" / 61 x 22.9 mm |
|---|
| Weight | 3.21 oz / 91 g |
|---|
Package Information | Package | 2.73 lb / 1.24 kg |
|---|
| Box Dimensions | 10 x 7.6 x 5.7" |
|---|
|
