Imaging | Lens Mount | Micro Four Thirds |
|---|
| Resolution | Actual: 21.8 Megapixel Effective: 20.4 Megapixel (5184 x 3888) |
|---|
| Sensor Type | 17.4 x 13 mm (Four Thirds) MOS |
|---|
| Crop Factor | 2x |
|---|
| Stabilization | Sensor-Shift, 5-Axis |
|---|
| ND Filter | None |
|---|
| Capture Type | Stills & Video |
|---|
Exposure Control | Shutter Type | Mechanical Focal Plane Shutter, Electronic Shutter |
|---|
| Shutter | Mechanical Shutter 1/8000 to 60 Seconds Up to 3 Hours in Bulb Mode Electronic Front Curtain Shutter 1/320 to 60 Seconds Electronic Shutter 1/32000 to 60 Seconds |
|---|
| Bulb | Bulb Mode, Time Mode |
|---|
| ISO | 200 to 25,600 in Auto Mode (Extended: 64 to 25,600) |
|---|
| Metering Method | Center-Weighted Average, Multi-Zone, Spot |
|---|
| Exposure Modes | Aperture Priority, Auto, Manual, Program, Shutter Priority |
|---|
| Exposure Compensation | -5 to +5 EV (1/3, 1/2, 1 EV Steps) |
|---|
| Metering Range | -2 to 20 EV |
|---|
| White Balance | Presets: Auto, Color Temperature |
|---|
| Continuous Shooting | Up to 10 fps at 20.4 MP for up to 150 Frames (Raw) / Unlimited Frames (JPEG) Up to 6 fps at 20.4 MP for Unlimited Frames (Raw) / Unlimited Frames (JPEG) Up to 30 fps at 20.4 MP for up to 23 Frames (Raw) / 26 Frames (JPEG) |
|---|
| Interval Recording | + |
|---|
| Self-Timer | 2/12-Second Delay |
|---|
Image | Image Sizes | 4:3 Raw 5184 x 3888 4:3 JPEG 5188 x 3888 3200 x 2400 1920 x 1440 1280 x 960 1024 x 768 |
|---|
| Aspect Ratio | 4:3 |
|---|
| Format | JPEG, Raw |
|---|
| Depth | 12-Bit |
|---|
Internal Video | Recording Modes | MOV/H.264 DCI 4K (4096 x 2160) at 24.00p (237 Mb/s) UHD 4K (3840 x 2160) at 23.98p/25p/29.97p (102 Mb/s) Full HD (1920 x 1080) at 23.98p/25p/29.97p/50p/59.94p/119.88p (18 to 202 Mb/s) HD (1280 x 720) at 23.98p/25p/29.97p/50p/59.94p (10 to 102 Mb/s) |
|---|
| Rec Limit | Up to 29 Minutes |
|---|
| Broadcast Output | NTSC/PAL |
|---|
| Microphone | Stereo |
|---|
| Audio Recording | 2-Channel LPCM Audio |
|---|
External Video Capture | External Recording | 4:2:2 8-Bit via HDMI DCI 4K (4096 x 2160) up to 24.00p |
|---|
| IP Streaming | None |
|---|
Interface | Media | Single Slot: SD/SDHC/SDXC (UHS-II) |
|---|
| Video | 1 x Micro-HDMI Output |
|---|
| Audio | 1 x 1/8" / 3.5 mm TRS Stereo Microphone Input |
|---|
| Power | 1 x USB Micro-B Input/Output |
|---|
| Other | 1 x USB Micro-B (USB 2.0) Input/Output (Shared with Power Input) 1 x 2.5 mm Sub-Mini Control Input |
|---|
| Wireless | Bluetooth, Wi-Fi |
|---|
| GPS | None |
|---|
Monitor | Size | 3.0" |
|---|
| Resolution | 1,040,000 Dot |
|---|
| Display | Touchscreen LCD |
|---|
Viewfinder | Type | Built-In Electronic (OLED) |
|---|
| Resolution | 2,360,000 Dot |
|---|
| Eye Point | 27 mm |
|---|
| Coverage | 100% |
|---|
| Magnification | Approx. 0.67x |
|---|
| Diopter Adjustment | -4 to +2 |
|---|
Focus | Type | Auto and Manual Focus |
|---|
| Mode | Continuous-Servo AF, Manual Focus, Single-Servo AF |
|---|
| Autofocus Points | Phase Detection: 121 (121 Cross-Type) Contrast Detection: 121 |
|---|
Flash | Built-In | - |
|---|
| Modes | Fill Flash, Off, Red-Eye Reduction, Second-Curtain Sync, Slow Sync, Slow Sync/Red-Eye Reduction |
|---|
| Max. Sync Speed | 1/250 Second |
|---|
| Compensation | -3 to +3 EV (1/3, 1/2, 1 EV Steps) |
|---|
| System | TTL |
|---|
| External Connection | Hot Shoe |
|---|
Environmental | Temperature | 14 to 104°F / -10 to 40°C |
|---|
| Storage Temperature | -4 to 140°F / -20 to 60°C |
|---|
| Humidity | 30 to 90% |
|---|
| Storage Humidity | 10 to 90% |
|---|
General | Battery | 1 x BLS-50 Rechargeable Lithium-Ion, 7.2 VDC, 1175 mAh (Approx. 310 Shots) |
|---|
| Tripod Mounting | 1 x 1/4"-20 Female (Bottom) |
|---|
| Accessory Mount | 1 x Hot Shoe Mount |
|---|
| WxHxD | 4.93 x 3.35 x 1.96" / 125.3 x 85.2 x 49.7 mm |
|---|
| Weight | 14.6 oz / 414 g (With Battery, Recording Media) |
|---|
Kit Lens | Focal | 12 to 45mm (35mm Equivalent Focal Length: 24 to 90mm) |
|---|
| Max Aperture | f/4 |
|---|
| Min Aperture | f/22 |
|---|
| Angle of View | 84° to 27° |
|---|
| Max. Magnification | 0.5x |
|---|
| Macro Reproduction Ratio | 1:2 |
|---|
| Min. Focus Distance | 0.39' / 12 cm |
|---|
| Optical | 12 Elements in 9 Groups |
|---|
| Diaphragm Blades | 7, Rounded |
|---|
| Focus Type | Autofocus |
|---|
| Image Stabilization | - |
|---|
| Filter Size | 58 mm (Front) |
|---|
| Dimensions (ø x L) | 2.5 x 2.76" / 63.4 x 70 mm |
|---|
| Weight | 8.96 oz / 254 g |
|---|
Packaging | Weight | 3.85 lb / 1.75 kg |
|---|
| Box LxWxH | 11.2 x 7.5 x 5.1" |
|---|
|
