Imaging | Lens Mount | Canon RF |
|---|
| Resolution | Effective: 24.2 Megapixel |
|---|
| Sensor | 22.3 x 14.9 mm (APS-C) CMOS |
|---|
| Crop Factor | 1.6x |
|---|
| Stabilization | - |
|---|
| ND Filter | - |
|---|
| Capture Type | Stills & Video |
|---|
Exposure Control | Shutter Type | Electronic Shutter |
|---|
| Shutter | Electronic Shutter
1/8000 Up to 30 Seconds
Electronic Front Curtain Shutter
1/4000 Up to 30 Seconds |
|---|
| Bulb | Bulb Mode, Time Mode |
|---|
| ISO | 100 to 32,000 (Extended: 51,200) |
|---|
| Metering Method | Center-Weighted Average, Evaluative, Partial, Spot |
|---|
| Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
|---|
| Exposure Compensation | -3 to +3 EV (1/3 EV Steps) |
|---|
| Metering Range | -2 to 20 EV |
|---|
| White Balance | Presets: Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten |
|---|
| Continuous Shooting | Electronic Shutter
Up to 15 fps for up to 28 Frames (JPEG) / 7 Frames (Raw)
Electronic Shutter
Up to 12 fps for up to 42 Frames (JPEG) / 7 Frames (Raw) |
|---|
| Interval Recording | + |
|---|
| Self-Timer | 2/10-Second Delay |
|---|
Image | Aspect Ratio | 3:2 |
|---|
| Format | C-RAW, HEIF, JPEG, Raw |
|---|
Video | Internal Recording | H.264/H.265/MPEG-4
UHD 4K (3840 x 2160) at 23.98/25/29.97 fps
1920 x 1080 at 23.98/25/29.97/50/59.94/100/120 fps |
|---|
| External Rec | - |
|---|
| Rec Limit | Not Specified by Manufacturer |
|---|
| Broadcast Output | NTSC/PAL |
|---|
| IP Streaming | + |
|---|
| Microphone | Stereo |
|---|
Interface | Media | Single Slot: SD/SDHC/SDXC |
|---|
| Video | 1 x Mini-HDMI Output |
|---|
| Audio | 1 x 1/8" / 3.5 mm TRS Stereo Microphone Input on Camera Body |
|---|
| Other | 1 x USB-C Input/Output |
|---|
| Wireless | 2.4 / 5 GHz Bluetooth 4.2
Wi-Fi |
|---|
| Mobile App | Yes
*As of February, 2023 |
|---|
| GPS | - |
|---|
Monitor | Size | 3" |
|---|
| Resolution | 1,620,000 Dot |
|---|
| Display | Touchscreen LCD |
|---|
Viewfinder | Type | Built-In Electronic |
|---|
| Size | 0.39" |
|---|
| Resolution | 2,360,000 Dot |
|---|
| Eye Point | 22 mm |
|---|
| Coverage | 100% |
|---|
| Magnification | Approx. 96x |
|---|
| Diopter Adjustment | -3 to +1 |
|---|
Focus | Type | Auto and Manual Focus |
|---|
| Mode | Continuous-Servo AF, Manual Focus, Single-Servo AF |
|---|
| Autofocus Points | Photo
Phase Detection: 4503
Video
3713 |
|---|
| Autofocus Sensitivity | -4 to +20 EV |
|---|
Flash | Built-In | + |
|---|
| Max. Sync Speed | 1/250 Second |
|---|
| Compensation | -3 to +3 EV (1/3 EV Steps) |
|---|
| System | eTTL |
|---|
| External Connection | Intelligent Hot Shoe |
|---|
Environmental | Temperature | 32 to 104°F / 0 to 40°C |
|---|
| Humidity | 0 to 85% (Recommended) |
|---|
General | Battery | 1 x LP-E17 Rechargeable Lithium Polymer, 7.2 VDC, 1040 mAh |
|---|
| PoE | + |
|---|
| Tripod Mounting | 1 x 1/4"-20 Female (Bottom) |
|---|
| WxHxD | 4.6 x 3.4 x 2.7" / 116.8 x 86.4 x 68.6 mm |
|---|
| Weight | 13.2 oz / 375 g (With Battery, Recording Media)
11.6 oz / 328 g (Body Only) |
|---|
Kit Lens | Focal | 18 to 45mm (35mm Equivalent: 29 to 72mm) |
|---|
| Max Aperture | f/4.5 to 6.3 |
|---|
| Min Aperture | f/32 |
|---|
| Angle of View | 74° 20' to 33° 40' |
|---|
| Max. Magnification | 0.16x |
|---|
| Min. Focus Distance | 7.9" / 20 cm |
|---|
| Optical | 7 Elements in 7 Groups |
|---|
| Diaphragm Blades | 7, Rounded |
|---|
| Focus Type | Autofocus |
|---|
| Image Stabilization | + |
|---|
| Filter Size | 49 mm (Front) |
|---|
| Dimensions (ø x L) | 2.7 x 1.7" / 68.9 x 44.3 mm |
|---|
| Weight | 4.6 oz / 130 g |
|---|
Packaging | Weight | 2.14 lb / 0.97 kg |
|---|
| Box LxWxH | 8 x 6.8 x 5.6" |
|---|
|
