Imaging | Lens Mount | Micro Four Thirds |
|---|
| Camera Format | Micro Four Thirds (2x Crop Factor) |
|---|
| Resolution | Actual: 21.77 Megapixel
Effective: 20.3 Megapixel (5184 x 3888) |
|---|
| Max. Resolution | 5184 x 3888 |
|---|
| Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
|---|
| Sensor Type | MOS |
|---|
| Sensor Size | 17.3 x 13 mm |
|---|
| Format | JPEG, Raw |
|---|
| Stabilization | Sensor-Shift, 5-Axis |
|---|
Exposure Control | ISO | Auto, 200 to 25600 (Extended: 100 to 25600) |
|---|
| Shutter | Electronic Front Curtain Shutter
1/8000 to 60 Seconds
1 to 30 Minutes in Bulb Mode
Electronic Shutter
1/32000 to 1 Second 1/16000 to 1/25 Second in Movie Mode |
|---|
| Metering Method | Center-Weighted Average, Multiple, Spot |
|---|
| Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
|---|
| Exposure Compensation | -5 to +5 EV (1/3 EV Steps) |
|---|
| Metering Range | 0 to 18 EV |
|---|
| White Balance | Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set |
|---|
| Continuous Shooting | Up to 9 fps at 20.3 MP
Up to 12 fps at 20.3 MP
Up to 20 fps at 20.3 MP
Up to 60 fps at 20.3 MP
Up to 30 fps at 18 MP
Up to 60 fps at 8 MP |
|---|
| Interval Recording | + |
|---|
| Self-Timer | 2/10-Second Delay |
|---|
Video | Recording Modes | MP4 4:2:0 8-Bit
UHD 4K (3840 x 2160) at 59.94p (150 Mb/s)
UHD 4K (3840 x 2160) at 23.976p/29.97p/59.94p (100 Mb/s)
Full HD (1920 x 1080) at 59.94p (28 Mb/s)
Full HD (1920 x 1080) at 29.97p/180p (20 Mb/s)
AVCHD
Full HD (1920 x 1080) at 59.94p (28 Mb/s)
Full HD (1920 x 1080) at 59.94i (17 to 24 Mb/s)
Full HD (1920 x 1080) at 23.976p (24 Mb/s) |
|---|
| External Recording | 4:2:2 8-Bit
UHD 4K (3840 x 2160)
Full HD (1920 x 1080) |
|---|
| Rec Limit | Up to 29 Minutes, 59 Seconds |
|---|
| Video Encoding | NTSC |
|---|
| Audio Recording | Built-In Microphone (Stereo)
External Microphone Input |
|---|
| Audio File Format | AAC, Dolby Digital 2ch, Linear PCM |
|---|
Focus | Type | Auto and Manual Focus |
|---|
| Mode | Continuous-Servo AF (C), Flexible (AFF), Manual Focus (M), Single-Servo AF (S) |
|---|
| Autofocus Points | Contrast Detection: 225 |
|---|
| Autofocus Sensitivity | -4 to +18 EV |
|---|
Viewfinder and Monitor | Viewfinder Type | Electronic |
|---|
| Viewfinder Resolution | 3,680,000 Dot |
|---|
| Viewfinder Eye Point | 21 mm |
|---|
| Viewfinder Coverage | 100% |
|---|
| Viewfinder Magnification | Approx. 0.83x |
|---|
| Diopter Adjustment | -4 to +3 |
|---|
| Size | 3" |
|---|
| Resolution | 1,040,000 Dot |
|---|
| Display | Touchscreen LCD |
|---|
Flash | Built-In | - |
|---|
| Modes | Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction |
|---|
| Max. Sync Speed | 1/250 Second |
|---|
| Compensation | -3 to +3 EV (1/3 EV Steps) |
|---|
| System | TTL |
|---|
| External Connection | Hot Shoe, PC Terminal |
|---|
Interface | Media | Dual Slot: SD/SDHC/SDXC (UHS-II) |
|---|
| Connectivity | 3.5mm Headphone, 3.5mm Microphone, 2.5mm Sub-Mini, HDMI A (Full Size), USB Micro-B (USB 3.0) |
|---|
| Wireless | Wi-FiBluetooth |
|---|
| GPS | - |
|---|
Environmental | Temperature | 14 to 104°F / -10 to 40°C |
|---|
| Humidity | 10 to 80% |
|---|
Physical | Battery | 1 x DMW-BLF19 Rechargeable Lithium-Ion, 7.2 VDC, 1860 mAh |
|---|
| WxHxD | 5.4 x 3.8 x 3.6" / 136.9 x 97.3 x 91.6 mm |
|---|
| Weight | 1.27 lb / 579 g (Body Only) |
|---|
Packaging | Weight | 2.945 lb / 1.34 kg |
|---|
| Box LxWxH | 7.75 x 6.05 x 5.75" |
|---|
|
