Imaging | Lens Mount | Micro Four Thirds |
|---|
| Camera Format | Micro Four Thirds (2x Crop Factor) |
|---|
| Pixels | Actual: 17.2 Megapixel
Effective: 16.05 Megapixel |
|---|
| Max. Resolution | 4608 x 3456 |
|---|
| Aspect Ratio | 4:3 |
|---|
| Sensor Type | MOS |
|---|
| Sensor Size | 17.3 x 13 mm |
|---|
| Format | JPEG, MPO, Raw |
|---|
| Stabilization | - |
|---|
Exposure Control | ISO | 200 to 25600 (Extended: 100 to 25600) |
|---|
| Shutter | 1/8000 to 60 Seconds
0 to 60 Minutes in Bulb Mode
1/16000 to 1/24 Second in Movie Mode |
|---|
| Metering Method | Center-Weighted Average, Multiple, Spot |
|---|
| Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
|---|
| Exposure Compensation | -5 to +5 EV (1/3 EV Steps) |
|---|
| Metering Range | 0 to 18 EV |
|---|
| White Balance | Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set |
|---|
| Continuous Shooting | Up to 40 fps |
|---|
| Interval Recording | + |
|---|
| Self-Timer | 2/10-Second Delay |
|---|
Video | Mode | MOV
DCI 4K (4096 x 2160) at 24.00p (100 Mb/s)
UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p (100 Mb/s)
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p (200 Mb/s)
MP4
DCI 4K (4096 x 2160) at 24.00p (100 Mb/s)
UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p (100 Mb/s)
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p (200 Mb/s)
Full HD (1920 x 1080) at 25p/29.97p (20 Mb/s)
Full HD (1920 x 1080) at 50p/59.94p (28 Mb/s)
HD (1280 x 720) at 25p/29.97p (10 Mb/s)
SD (640 x 480) at 25p/29.97p (4 Mb/s)
AVCHD
Full HD (1920 x 1080) at 23.976p (24 Mb/s)
Full HD (1920 x 1080) at 50p/59.94p (28 Mb/s)
Full HD (1920 x 1080) at 50i/59.94i (24 Mb/s)
Full HD (1920 x 1080) at 50i/59.94i (17 Mb/s) |
|---|
| External Rec | 4:2:2 10-Bit |
|---|
| Rec Limit | Up to 220 Minutes |
|---|
| Encoding | NTSC/PAL |
|---|
| Audio | Built-In Microphone (Stereo)
External Microphone Input |
|---|
| Audio Format | AAC, Dolby Digital 2ch, Linear PCM |
|---|
Focus | Type | Auto and Manual Focus |
|---|
| Mode | Continuous-Servo AF (C), Flexible (AFF), Manual Focus (M), Single-Servo AF (S) |
|---|
| Autofocus Sensitivity | -4 to +18 EV |
|---|
Viewfinder and Monitor | Type | Electronic |
|---|
| Resolution | 2,359,000 Dot |
|---|
| Eye Point | 21 mm |
|---|
| Coverage | 100% |
|---|
| Magnification | Approx. 1.34x |
|---|
| Diopter Adjustment | -4 to +4 |
|---|
| Size | 3" |
|---|
| Resolution | 1,036,000 Dot |
|---|
| Display | Touchscreen OLED |
|---|
Flash | Built-In | + |
|---|
| Modes | Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction |
|---|
| Max. Sync Speed | 1/250 Second |
|---|
| Compensation | -3 to +3 EV (1/3 EV Steps) |
|---|
| System | TTL |
|---|
| External Connection | Hot Shoe |
|---|
Interface | Media | Single Slot: SD/SDHC/SDXC (UHS-I) |
|---|
| Connectivity | USB Type-B (USB 2.0), HDMI D (Micro), 3.5mm Headphone, 3.5mm Microphone, 2.5mm Sub-Mini |
|---|
| Wireless | Wi-Fi |
|---|
| GPS | - |
|---|
Environmental | Temperature | 32 to 104°F / 0 to 40°C |
|---|
| Humidity | 10 to 80% |
|---|
Physical | Battery | 1 x Rechargeable Lithium-Ion, 7.2 VDC, 1860 mAh (Approx. 530 Shots) |
|---|
| WxHxD | 5.23 x 3.68 x 3.3" / 132.9 x 93.4 x 83.9 mm |
|---|
| Weight | 1.23 lb / 560 g (Body with Battery and Memory) |
|---|
Packaging | Weight | 2.84 lb / 1.29 kg |
|---|
| Box LxWxH | 7.65 x 5.9 x 5.8" |
|---|
|
