Key Specs | Lens Mount | Micro Four Thirds |
|---|
| Resolution | Actual: 22.9 Megapixel
Effective: 20.4 Megapixel |
|---|
| Sensor | 17.4 x 13 mm (Four Thirds) BSI MOS |
|---|
| Stabilisation | Sensor-Shift, 5-Axis |
|---|
| ISO Sensitivity Range | Photo/Video
200 to 25,600 in Manual, Auto Mode (Extended: 80 to 102,400) |
|---|
| Burst | Up to 120 fps |
|---|
| External Recording | 4:2:2/Raw 8/12-Bit via HDMI
4096 x 2160
3840 x 2160
1920 x 1080
Show More |
|---|
| Media | Dual Slot: SD/SDHC/SDXC (UHS-II) |
|---|
| Video | 1x Micro-HDMI (Unspecified Signal) Output |
|---|
| Audio | 1x 1/8" / 3.5 mm TRS Stereo Microphone Input
1x 1/8" / 3.5 mm TRS Stereo Headphone Output |
|---|
| Power | 1x USB-C Input/Output |
|---|
| Other | 1x USB-C Data Input/Output (Shared with Power Input)
1x PC Sync Socket |
|---|
| Wireless | 2.4 / 5 GHz Wi-Fi 5 (802.11ac), Bluetooth 4.2 |
|---|
| Screen Type | Articulating Touchscreen LCD |
|---|
| Battery Type | 1x BLX-1 Rechargeable Lithium-Ion (Approx. 500 Shots) |
|---|
Image | Lens Mount | Micro Four Thirds |
|---|
| Sensor Resolution | Actual: 22.9 Megapixel
Effective: 20.4 Megapixel |
|---|
| Image Sensor | 17.4 x 13 mm (Four Thirds) BSI MOS |
|---|
| Sensor Crop (35mm Equivalent) | Crop Factor: 2x |
|---|
| Image Stabilization | Sensor-Shift, 5-Axis |
|---|
| Capture Type | Stills & Video |
|---|
Exposure | Shutter Type | Mechanical Focal Plane Shutter and Electronic Rolling Shutter |
|---|
| Bulb/Time Mode | Bulb Mode, Time Mode |
|---|
| ISO Sensitivity Range | Photo/Video
200 to 25,600 in Manual, Auto Mode (Extended: 80 to 102,400) |
|---|
| Metering | Center-Weighted Average, Highlight, Multi-Zone, Spot |
|---|
| Precise Scan Rate Control | Yes |
|---|
| Exposure | Aperture Priority, Manual, Program, Shutter Priority |
|---|
| Compensation | -5 to +5 EV (1/3, 1/2, 1 EV Steps) |
|---|
| Metering Range | -2 to 20 EV |
|---|
| Burst | Up to 120 fps |
|---|
| Interval Recording | Yes |
|---|
Still Photography | Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
|---|
| Format | JPEG, Raw |
|---|
| Bit Depth | 12-Bit |
|---|
Video | External Recording Modes | 4:2:2/Raw 8/12-Bit via HDMI
4096 x 2160
3840 x 2160
1920 x 1080 |
|---|
| Fast, Slow Motion | Slow-Motion Only |
|---|
| Gamma Curve | FLAT, HDR-HLG, OM-Log |
|---|
| Built-In Microphone | Stereo |
|---|
| Audio | 16-Bit 48 kHz LPCM Audio |
|---|
Connectivity | Media/Memory Card Slot | Dual Slot: SD/SDHC/SDXC (UHS-II) |
|---|
| Video I/O | 1x Micro-HDMI (Unspecified Signal) Output |
|---|
| Audio | 1x 1/8" / 3.5 mm TRS Stereo Microphone Input
1x 1/8" / 3.5 mm TRS Stereo Headphone Output |
|---|
| Power | 1x USB-C Input/Output |
|---|
| Other I/O | 1x USB-C Data Input/Output (Shared with Power Input)
1x PC Sync Socket |
|---|
| Wireless | 2.4 / 5 GHz Wi-Fi 5 (802.11ac), Bluetooth 4.2 |
|---|
| Satnav (GPS, GLONASS, etc.) | GPS
*Via Connected Smartphone |
|---|
Screen | Screen Size | 3" |
|---|
| Resolution | 1,620,000 Dot |
|---|
| Display Type | Articulating Touchscreen LCD |
|---|
Viewfinder | Type | Built-In Electronic (OLED) |
|---|
| Resolution | 5,760,000 Dot |
|---|
| Eye Point | 21 mm |
|---|
| Coverage | 100% |
|---|
| Magnification | Approx. 1.48x |
|---|
| Diopter Adjustment | -4 to +2 |
|---|
Focus | Focusing | Auto and Manual Focus |
|---|
| Focus Modes | Continuous-Servo AF, Manual Focus, Single-Servo AF |
|---|
| AF Points | Photo, Video
Phase Detection: 1053 |
|---|
Flash | Modes | Fill In, Manual, Off, Red-Eye Reduction, Slow Sync |
|---|
| Max. Sync Speed | 1/250 Second |
|---|
| Flash Compensation | -3 to +3 EV (1/3, 1/2, 1 EV Steps) |
|---|
| Dedicated Flash System | TTL |
|---|
| External Connection | Shoe Mount, PC Terminal |
|---|
Environmental | Operating Temperature | 14 to 104°F / -10 to 40°C |
|---|
| Storage Temperature | -4 to 140°F / -20 to 60°C |
|---|
| Operating Humidity | 30 to 90% |
|---|
| Storage Humidity | 10 to 90% |
|---|
General Information | Battery Type | 1x BLX-1 Rechargeable Lithium-Ion (Approx. 500 Shots) |
|---|
| Shoe Mount | 1x Hot Shoe |
|---|
| Tripod Mounting Thread | 1x 1/4"-20 Female (Bottom) |
|---|
| Material | Magnesium Alloy |
|---|
| WxHxD | 5.3 x 3.6 x 2.9" / 134.8 x 91.6 x 72.7 mm |
|---|
| Weight | 1.1 lb / 511 g (Body Only) |
|---|
Package Information | Package | 3 lb / 1.36 kg |
|---|
| Box Dimensions | 7.5 x 7.5 x 5.75" / 18.78 x 18.78 x 14.4 cm |
|---|
Key Specs | Focal | 12 to 40mm (35mm Equivalent: 24 to 80mm) |
|---|
| Max Aperture | f/2.8 |
|---|
| Lens Mount | Micro Four Thirds |
|---|
| Lens Format Coverage | Micro Four Thirds |
|---|
| Focus Type | Autofocus |
|---|
| Filter Size | 62 mm (Front) |
|---|
| Max. Aperture | f/2.8 |
|---|
| Min Aperture | f/22 |
|---|
| Lens Mount | Micro Four Thirds |
|---|
| Lens Format Coverage | Micro Four Thirds |
|---|
| Angle of View | 84° 30 |
|---|
| Min. Focus Distance | 7.9" / 20 cm |
|---|
| Max. Magnification | 0.3x |
|---|
| Optical | 14 Elements in 9 Groups |
|---|
| Diaphragm Blades | 7, Rounded |
|---|
| Focus Type | Autofocus |
|---|
| Filter Size | 62 mm (Front) |
|---|
| Dimensions (ø x L) | 2.8 x 3.3" / 70 x 84 mm |
|---|
| Weight | 13.5 oz / 382 g |
|---|
Packaging Info | Package | 1.42 lb / 0.64 kg |
|---|
| Box Dimensions (LxWxH) | 8.5 x 4.6 x 4.6" / 21.28 x 11.52 x 11.52 cm |
|---|
|
