Imaging | Lens Mount | Micro Four Thirds |
|---|
| Resolution | Actual: 21.8 Megapixel
Effective: 20.4 Megapixel |
|---|
| Sensor | 17.4 x 13 mm (Four Thirds) MOS |
|---|
| Crop Factor | 2x |
|---|
| Stabilization | Sensor-Shift, 5-Axis |
|---|
| ND Filter | 4 Stop Electronic ND Filter |
|---|
| Capture Type | Stills & Video |
|---|
Exposure Control | Shutter Type | Electronic Shutter, Mechanical Focal Plane Shutter |
|---|
| Shutter | Mechanical Shutter
1/8000 to 60 Seconds
Electronic Front Curtain Shutter
1/320 to 60 Seconds
Electronic Shutter
1/32000 to 60 Seconds |
|---|
| Bulb | Bulb Mode, Time Mode |
|---|
| ISO | 200 to 25,600 (Extended: 64 to 25,600) |
|---|
| Metering Method | Center-Weighted Average, Multi-Zone, Spot |
|---|
| Exposure Modes | Aperture Priority, Auto, Manual, Program, Shutter Priority |
|---|
| Exposure Compensation | -5 to +5 EV (1/3, 1/2, 1 EV Steps) |
|---|
| Metering Range | -2 to 20 EV |
|---|
| White Balance | Presets: Auto, Color Temperature, Custom |
|---|
| Continuous Shooting | Up to 10 fps at 20.4 MP for up to 149 Frames (Raw) / Unlimited Frames (JPEG)
Up to 6 fps at 20.4 MP for Unlimited Frames (Raw) / Unlimited Frames (JPEG)
Up to 30 fps at 20.4 MP for up to 18 Frames (Raw) / 20 Frames (JPEG)
Up to 10 fps at 20.4 MP for up to 138 Frames (Raw) / Unlimited Frames (JPEG) |
|---|
| Interval Recording | + |
|---|
Image | Image Sizes | 4:3 JPEG / Raw
20.4 MP (5184 x 3888)
4:3 JPEG
20.4 MP (1024 x 768)
4:3 JPEG
50 MP (8160 x 6120) |
|---|
| Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
|---|
| Format | JPEG, Raw |
|---|
| Depth | 12-Bit |
|---|
Video | Internal Recording | H.264/MOV/MPEG-4 AVC
DCI 4K (4096 x 2160) at 24.00 fps (237 Mb/s)
H.264/MOV/MPEG-4 AVC
UHD 4K (3840 x 2160) at 24.00/25/29.97 fps (102 Mb/s)
H.264/MOV/MPEG-4 AVC
1920 x 1080 at 24.00/25/29.97 fps (18 to 202 Mb/s)
H.264/MOV/MPEG-4 AVC
1280 x 720 at 24.00/25/29.97/50/59.94 fps (102 Mb/s)
MOV
1920 x 1080 |
|---|
| Rec Limit | - |
|---|
| Broadcast Output | NTSC/PAL |
|---|
| Microphone | Stereo |
|---|
Interface | Media | Single Slot: SD/SDHC (UHS-II) |
|---|
| Video | 1 x Micro-HDMI Output |
|---|
| Audio | 1 x 1/8" / 3.5 mm TRS Stereo Microphone Input |
|---|
| Power | 1 x Micro-USB Input/Output |
|---|
| Other | 1 x 2.5 mm Sub-Mini Control |
|---|
| Wireless | Wi-Fi (802.11b/g), Bluetooth |
|---|
| GPS | - |
|---|
Monitor | Size | 3" |
|---|
| Resolution | 1,040,000 Dot |
|---|
| Display | Touchscreen LCD |
|---|
Viewfinder | Type | Built-In Electronic (OLED) |
|---|
| Resolution | 2,360,000 Dot |
|---|
| Eye Point | 27 mm |
|---|
| Coverage | 100% |
|---|
| Diopter Adjustment | -4 to +2 |
|---|
Focus | Type | Auto and Manual Focus |
|---|
| Mode | Continuous-Servo AF, Manual Focus, Single-Servo AF |
|---|
| Autofocus Points | Contrast Detection, Phase Detection: 121 (121 Cross-Type) |
|---|
Flash | Built-In | - |
|---|
| Modes | Fill Flash, Manual, Off, Red-Eye Reduction, Second-Curtain Sync, Slow Sync, Slow Sync/Red-Eye Reduction |
|---|
| Max. Sync Speed | 1/250 Second |
|---|
| Compensation | -3 to +3 EV (1/3, 1 EV Steps) |
|---|
| System | TTL |
|---|
| External Connection | Hot Shoe |
|---|
Environmental | Temperature | 14 to 104°F / -10 to 40°C |
|---|
| Storage Temperature | -4 to 140°F / -20 to 60°C |
|---|
| Humidity | 30 to 90% |
|---|
| Storage Humidity | 10 to 90% |
|---|
General | Battery | 1 x BLS-50 Rechargeable Lithium-Ion (Approx. 310 Shots) |
|---|
| Tripod Mounting | 1 x 1/4"-20 Female (Bottom) |
|---|
| WxHxD | 4.9 x 3.4 x 2" / 125.3 x 85.2 x 49.7 mm |
|---|
| Weight | 12.9 oz / 366 g (Body Only)
14.6 oz / 414 g (With Battery) |
|---|
Packaging | Weight | 2.295 lb / 1.04 kg |
|---|
| Box LxWxH | 8.5 x 7.4 x 5.5" |
|---|
|
