Imaging | Lens Mount | Micro Four Thirds |
|---|
| Sensor Type | 17.3 x 13 mm (4/3") MOS |
|---|
| Resolution | Actual: 21.77 Megapixel
Effective: 20.3 Megapixel (8176 x 1920) |
|---|
| Crop Factor | 2x |
|---|
| Aspect Ratio | 4:3 |
|---|
| Format | JPEG, Raw |
|---|
| Stabilization | Sensor-Shift, 5-Axis |
|---|
Exposure Control | ISO | 200 to 25600 (Extended: 100 to 25600) |
|---|
| Shutter | Electronic Shutter
1/16000 to 1 Second
Bulb Mode
Electronic Front Curtain Shutter
1/2000 to 60 Seconds
Bulb Mode |
|---|
| Metering Method | Center-Weighted Average, Multiple, Spot |
|---|
| Exposure Modes | Aperture Priority, Auto, Manual, Program, Shutter Priority |
|---|
| Exposure Compensation | -5 to +5 EV (1/3 EV Steps) |
|---|
| White Balance | Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4 |
|---|
| Continuous Shooting | Up to 9 fps at 20.3 MP for up to 30 Frames (Raw) / 600 Frames (JPEG)
Up to 6 fps at 20.3 MP for up to 30 Frames (Raw) / 600 Frames (JPEG)
Up to 2 fps at 20.3 MP for up to 30 Frames (Raw) / 600 Frames (JPEG)
Up to 30 fps at 8.3 MP (JPEG) |
|---|
| Interval Recording | + |
|---|
| Self-Timer | 10-Second Delay |
|---|
Video | Recording Modes | MP4
UHD 4K (3840 x 2160) at 23.976p/29.97p (100 Mb/s)
Full HD (1920 x 1080) at 29.97p (20 Mb/s)
Full HD (1920 x 1080) at 59.94p (28 Mb/s)
HD (1280 x 720) at 29.97p (10 Mb/s)
AVCHD
Full HD (1920 x 1080) at 59.94p (28 Mb/s)
Full HD (1920 x 1080) at 59.94i (17 Mb/s)
Full HD (1920 x 1080) at 23.976p/59.94i (24 Mb/s) |
|---|
| External Recording | DCI 4K (4096 x 2160) |
|---|
| Video Encoding | NTSC |
|---|
| ISO Sensitivity | Auto: 200 to 6400 (Extended: 100 to 6400) |
|---|
| Audio Recording | Built-In Microphone (Stereo)
External Microphone Input |
|---|
| Audio File Format | AAC |
|---|
Focus | Type | Auto and Manual Focus |
|---|
| Mode | Automatic (A), Continuous-Servo AF (C), Flexible (AFF), Manual Focus (M) |
|---|
| Autofocus Points | Contrast Detection: 49 |
|---|
Viewfinder | Viewfinder Type | Electronic (OLED) |
|---|
| Viewfinder Resolution | 2,360,000 Dot |
|---|
| Viewfinder Eye Point | 20 mm |
|---|
| Viewfinder Coverage | 100% |
|---|
| Viewfinder Magnification | Approx. 0.74x |
|---|
| Diopter Adjustment | -4 to +4 |
|---|
Monitor | Size | 3.0" |
|---|
| Resolution | 1,240,000 Dot |
|---|
| Display | Touchscreen LCD |
|---|
Flash | Built-In | + |
|---|
| Modes | Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction |
|---|
| Guide Number | 9' / 2.7 m at ISO 200 |
|---|
| Max. Sync Speed | 1/200 Second |
|---|
| Compensation | -3 to +3 EV (1/3 EV Steps) |
|---|
| System | TTL |
|---|
| External Connection | Hot Shoe |
|---|
Interface | Media | Single Slot: SD/SDHC/SDXC (UHS-II) |
|---|
| Connectivity | USB Micro-B (USB 2.0) |
|---|
| Wireless | Wi-Fi |
|---|
| GPS | - |
|---|
Environmental | Temperature | 14 to 104°F / -10 to 40°C |
|---|
| Humidity | 10 to 80% |
|---|
Physical | Battery | 1 x DMW-BLC12 Rechargeable Lithium-Ion, 7.2 VDC, 1200 mAh (Approx. 290 Shots) |
|---|
| WxHxD | 5.1 x 3.7 x 3" / 130.4 x 93.5 x 77.4 mm |
|---|
| Weight | 1.06 lb / 484 g |
|---|
Packaging | Weight | 2.21 lb / 1.0 kg |
|---|
| Box LxWxH | 7.6 x 6.9 x 5.6" |
|---|
|
