Key Specs | Lens Mount | Micro Four Thirds |
|---|
| Resolution | Actual: 21.77 Megapixel
Effective: 20.3 Megapixel (5184 x 3888) |
|---|
| Sensor | 17.3 x 13 mm (Four Thirds) MOS |
|---|
| Stabilisation | Digital, 5-Axis |
|---|
| External Recording | 4:2:2 8-Bit via HDMI
1920 x 1080 |
|---|
| Media | Single Slot: SD/SDHC/SDXC (UHS-II) |
|---|
| Video | 1x Micro-HDMI Output |
|---|
| Audio | 1x 1/8" / 3.5 mm TRS Stereo Microphone Input |
|---|
| Power | 1x USB-C Input/Output |
|---|
| Other | 1x USB-C Data Input/Output (Shared with Power Input) |
|---|
| Wireless | Wi-Fi 4 (802.11n), Bluetooth 4.2 |
|---|
| Screen Type | Articulating Touchscreen LCD |
|---|
Image | Lens Mount | Micro Four Thirds |
|---|
| Sensor Resolution | Actual: 21.77 Megapixel
Effective: 20.3 Megapixel (5184 x 3888) |
|---|
| Image Sensor | 17.3 x 13 mm (Four Thirds) MOS |
|---|
| Sensor Crop (35mm Equivalent) | Crop Factor: 2x
*Additional Crop Occurs in Select Video Modes |
|---|
| Image Stabilization | Digital, 5-Axis |
|---|
| Capture Type | Stills & Video |
|---|
Exposure | Shutter Type | Mechanical Focal Plane Shutter and Electronic Rolling Shutter |
|---|
| Bulb/Time Mode | Bulb & Time Mode |
|---|
| ISO | Photo
Native: 200 to 25,600 (100 to 25,600 Extended)
Video
Native: 200 to 6400 |
|---|
| Metering | Center-Weighted Average, Multiple, Spot |
|---|
| Exposure | Aperture Priority, Auto, Manual, Program, Shutter Priority |
|---|
| Burst | Up to 10 fps at Max. Resolution for up to 20 Frames (Raw) / 480 Frames (JPEG) |
|---|
| Interval Recording | Yes |
|---|
| Self Timer | 2/10-Second Delay |
|---|
Still Photography | Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
|---|
| Format | JPEG, Raw |
|---|
Video | External Recording Modes | 4:2:2 8-Bit via HDMI
1920 x 1080 |
|---|
| Fast, Slow Motion | Yes |
|---|
| Rec Limit | 30-Minute Max. in 1080p
10-Minute Max. in 4K |
|---|
| Built-In Microphone | Stereo |
|---|
| Audio | AAC Audio |
|---|
Connectivity | Media/Memory Card Slot | Single Slot: SD/SDHC/SDXC (UHS-II) |
|---|
| Video I/O | 1x Micro-HDMI Output |
|---|
| Audio | 1x 1/8" / 3.5 mm TRS Stereo Microphone Input |
|---|
| Power | 1x USB-C Input/Output |
|---|
| Other I/O | 1x USB-C Data Input/Output (Shared with Power Input) |
|---|
| Wireless | Wi-Fi 4 (802.11n), Bluetooth 4.2 |
|---|
| Satnav (GPS, GLONASS, etc.) | GPS
*Via Connected Smartphone |
|---|
Screen | Screen Size | 3.0" |
|---|
| Resolution | 1,840,000 Dot |
|---|
| Display Type | Articulating Touchscreen LCD |
|---|
Viewfinder | Type | Electronic (OLED) |
|---|
| Size | 0.39" |
|---|
| Resolution | 2,360,000 Dot |
|---|
| Eye Point | 20 mm |
|---|
| Coverage | 100% |
|---|
| Magnification | Approx. 0.74x |
|---|
Focus | Focusing | Auto and Manual Focus |
|---|
| Focus Modes | Automatic, Continuous-Servo AF, Flexible, Manual Focus |
|---|
| AF Points | Contrast Detection: 49 |
|---|
Flash | Built-In Flash | Yes, Flash Only |
|---|
| Max. Sync Speed | 1/50 Second |
|---|
| Dedicated Flash System | TTL |
|---|
| External Connection | Shoe Mount |
|---|
General Information | Shoe Mount | 1x Hot Shoe |
|---|
| Tripod Mounting Thread | 1x 1/4"-20 Female (Bottom) |
|---|
| Operating Conditions | 32 to 104°F / 0 to 40°C at 10 to 80% Humidity |
|---|
| WxHxD | 4.55 x 3.25 x 2.13" / 115.6 x 82.5 x 54.2 mm (Without Protrusions) |
|---|
| Weight | 12.42 oz / 352 g (With Battery, Recording Media) |
|---|
Kit Lens | Focal | 12 to 32mm (35mm Equivalent: 24 to 120mm) |
|---|
| Aperture | Max.: f/3.5 to 5.6
Min.: f/22 |
|---|
| Angle of View | 84,05° to 20,44° |
|---|
| Min. Focus Distance | 7.87" / 20 cm |
|---|
| Optical | 11 Elements in 9 Groups |
|---|
| Aperture/Iris Blades | 7, Rounded |
|---|
| Focus Type | Autofocus |
|---|
| Image Stabilization | Yes |
|---|
| Filter Size | 58 mm (Front) |
|---|
| Dimensions | ø: 2.6 x L: 2.8" / ø: 66 x L: 71 mm |
|---|
| Weight | 7.41 oz / 210 g |
|---|
|
