Imaging | Lens Mount | Micro Four Thirds |
|---|
| Resolution | Actual: 22.9 Megapixel Effective: 20.4 Megapixel |
|---|
| Sensor Type | 17.4 x 13 mm (Four Thirds) MOS |
|---|
| Crop Factor | 2x |
|---|
| Stabilization | Sensor-Shift, 5-Axis |
|---|
| ND Filter | None |
|---|
| Capture Type | Stills & Video |
|---|
Exposure Control | Shutter Type | Electronic Shutter, Mechanical Focal Plane Shutter |
|---|
| Shutter | Mechanical Shutter 1/8000 to 60 Seconds Electronic Front Curtain Shutter 1/320 to 60 Seconds Electronic Shutter 1/32000 to 60 Seconds |
|---|
| Bulb | Bulb Mode, Time Mode |
|---|
| ISO | Photo/Video 200 to 102,400 in Manual, Auto Mode (Extended: 80 to 102,400) |
|---|
| Metering Method | Center-Weighted Average, Highlight Weighted, Multi-Zone, Spot |
|---|
| Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
|---|
| Exposure Compensation | -5 to +5 EV (1/3, 1/2, 1 EV Steps) |
|---|
| Metering Range | -2 to 20 EV |
|---|
| Continuous Shooting | Mechanical Shutter Up to 10 fps at 20.4 MP for up to 139 Frames (Raw) / 169 Frames (JPEG) Electronic Shutter Up to 20 fps at 20.4 MP for up to 108 Frames (Raw) / 116 Frames (JPEG) Up to 120 fps at 20.4 MP for up to 92 Frames (Raw) / 92 Frames (JPEG) Up to 50 fps at 20.4 MP for up to 96 Frames (Raw) / 97 Frames (JPEG) |
|---|
| Interval Recording | + |
|---|
Image | Image Sizes | 4:3 JPEG / Raw 20 MP (5184 x 3888) |
|---|
| Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
|---|
| Format | JPEG, Raw |
|---|
| Depth | 12-Bit |
|---|
Internal Video | Recording Modes | H.265 Long GOP/MOV 4:2:0 10-Bit DCI 4K (4096 x 2160) at 23.98p/25p/29.97p/50p/59.94p (77 to 152 Mb/s) UHD 4K (3840 x 2160) at 23.98p/25p/29.97p/50p/59.94p (77 to 152 Mb/s) Full HD (1920 x 1080) at 23.98p/24.00p/29.97p/50p/59.94p (22 to 42 Mb/s) H.265/MOV 4:2:0 10-Bit Full HD (1920 x 1080) at 23.98p/25p/29.97p/50p/59.94p (82 to 162 Mb/s) Full HD (1920 x 1080) at 100p/119.88p/200p H.264 Long GOP/MOV 4:2:0 8-Bit DCI 4K (4096 x 2160) at 23.98p/25p/29.97p/50p/59.94p (102 to 202 Mb/s) UHD 4K (3840 x 2160) at 23.98p/25p/29.97p/50p/59.94p (102 to 202 Mb/s) Full HD (1920 x 1080) at 23.98p/25p/29.97p/50p/59.94p (27 to 52 Mb/s) H.264/MOV 4:2:0 8-Bit Full HD (1920 x 1080) at 23.98p/25p/29.97p (202 Mb/s) Full HD (1920 x 1080) at 100p/119.88p/200p/239.76p |
|---|
| Gamma Curve | HDR-HLG, OM-Log |
|---|
| Broadcast Output | NTSC/PAL |
|---|
| Microphone | Stereo |
|---|
| Audio Recording | MOV: 2-Channel 24-Bit 96 kHz LPCM Audio MOV: 2-Channel 16-Bit 48 kHz LPCM Audio |
|---|
External Video Capture | External Recording | Raw 12-Bit via HDMI DCI 4K (4096 x 2160) UHD 4K (3840 x 2160) |
|---|
| IP Streaming | None |
|---|
Interface | Media | Dual Slot: SD/SDHC/SDXC (UHS-II) |
|---|
| Video | 1 x Micro-HDMI Output |
|---|
| Audio | 1 x 1/8" / 3.5 mm TRS Stereo Microphone (Plug-in Power) Input on Camera Body 1 x 1/8" / 3.5 mm TRS Stereo Headphone Output on Camera Body |
|---|
| Other | 1 x USB-C Input/Output (Shared with Power Input) 1 x 2.5 mm Sub-Mini 1 x PC Sync Socket FlashSync Output |
|---|
| Wireless | 2.4 / 5 GHz Wi-Fi Bluetooth |
|---|
| GPS | None |
|---|
Monitor | Size | 3.0" |
|---|
| Resolution | 1,620,000 Dot |
|---|
| Display | Touchscreen LCD |
|---|
Viewfinder | Type | Built-In Electronic (OLED) |
|---|
| Resolution | 5,760,000 Dot |
|---|
| Eye Point | 21 mm |
|---|
| Coverage | 100% |
|---|
Focus | Type | Auto and Manual Focus |
|---|
| Mode | Continuous-Servo AF, Manual Focus, Single-Servo AF |
|---|
| Autofocus Points | Photo, Video Phase Detection: 1053 |
|---|
| Autofocus Sensitivity | -6 to +19 EV |
|---|
Flash | Built-In | - |
|---|
| Modes | Fill Flash, First-Curtain Sync, Manual, Off, Red-Eye Reduction, Second-Curtain Sync, Slow Sync |
|---|
| Max. Sync Speed | 1/250 Second |
|---|
| Compensation | -3 to +3 EV (1/3, 1/2, 1 EV Steps) |
|---|
| System | TTL |
|---|
| External Connection | Hot Shoe, PC Terminal |
|---|
Environmental | Temperature | 22 to 72°F / -10 to 40°C |
|---|
| Storage Temperature | -4 to 140°F / -20 to 60°C |
|---|
| Humidity | 30 to 90% |
|---|
| Storage Humidity | 10 to 90% |
|---|
General | Battery | 1 x BLX-1 Rechargeable Lithium-Ion (Approx. 520 Shots) |
|---|
| Tripod Mounting | 1 x 1/4"-20 Female (Bottom) |
|---|
| Accessory Mount | 1 x Hot Shoe Mount on Camera Body |
|---|
| WxHxD | 5.3 x 3.6 x 2.9" / 134.8 x 91.6 x 72.7 mm |
|---|
| Weight | 1.3 lb / 599 g (With Battery, Recording Media) 1.1 lb / 511 g (Body Only) |
|---|
Packaging | Weight | 3.15 lb / 1.43 kg |
|---|
| Box LxWxH | 8.6 x 7.5 x 5.7" |
|---|
|
