Imaging | Lens Mount | Micro Four Thirds |
|---|
| Camera Format | Micro Four Thirds (2x Crop Factor) |
|---|
| Resolution | Actual: 11.93 Megapixel
Effective: 10.28 Megapixel (3680 x 2760) |
|---|
| Max. Resolution | 3680 x 2760 |
|---|
| Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
|---|
| Sensor Type | MOS |
|---|
| Sensor Size | 17.3 x 13 mm |
|---|
| Format | JPEG, Raw |
|---|
| Depth | 14-Bit |
|---|
| Stabilization | - |
|---|
Exposure Control | ISO | Auto, 160 to 51200 (Extended: 80 to 204800) |
|---|
| Shutter | Electronic Front Curtain Shutter
1/8000 to 60 Seconds
1 to 30 Minutes in Bulb Mode
1/16000 to 1/24 Second in Movie Mode
Electronic Shutter
1/16000 to 1 Second |
|---|
| Metering Method | Center-Weighted Average, Multiple, Spot |
|---|
| Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
|---|
| Exposure Compensation | -5 to +5 EV (1/3 EV Steps) |
|---|
| Metering Range | 0 to 18 EV |
|---|
| White Balance | Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4 |
|---|
| Continuous Shooting | Up to 12 fps at 10.3 MP for up to 80 Frames (Raw) / 600 Frames (JPEG)
Up to 8 fps at 10.3 MP
Up to 7 fps at 10.3 MP
Up to 6 fps at 10.3 MP
Up to 5 fps at 10.3 MP
Up to 2 fps at 10.3 MP
Up to 60 fps at 8 MP |
|---|
| Interval Recording | + |
|---|
| Self-Timer | 2/10-Second Delay |
|---|
Video | Mode | AVCHD
Full HD (1920 x 1080) at 50p/59.94p (28 Mb/s)
Full HD (1920 x 1080) at 50i/59.94i (17 to 24 Mb/s)
Full HD (1920 x 1080) at 23.976p (24 Mb/s)
MP4 4:2:0 10-Bit
UHD 4K (3840 x 2160) at 23.976p/25p/29.97p (72 Mb/s)
MOV/MP4 4:2:0 8-Bit
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p (100 Mb/s)
DCI 4K (4096 x 2160) at 50p/59.94p (150 Mb/s)
UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p (100 Mb/s)
UHD 4K (3840 x 2160) at 50p/59.94p (150 Mb/s)
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p (100 Mb/s)
Full HD (1920 x 1080) at 25p/29.97p (20 Mb/s)
Full HD (1920 x 1080) at 23.976p/24.00p (24 Mb/s)
Full HD (1920 x 1080) at 50p/59.94p (28 Mb/s)
MOV/MP4 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 23.976p/24.00p (150 to 400 Mb/s)
DCI 4K (4096 x 2160) at 25p/29.97p (150 Mb/s)
UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p (150 to 400 Mb/s)
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p (100 to 200 Mb/s) |
|---|
| External Rec | 4:2:2 10-Bit |
|---|
| Encoding | NTSC/PAL |
|---|
| Audio | Built-In Microphone (Stereo)
External Microphone Input |
|---|
| Audio Format | AAC, Dolby Digital 2ch, Linear PCM (Stereo) |
|---|
Focus | Type | Auto and Manual Focus |
|---|
| Mode | Continuous-Servo AF (C), Flexible (AFF), Manual Focus (M), Single-Servo AF (S) |
|---|
| Autofocus Points | Contrast Detection: 225 |
|---|
| Autofocus Sensitivity | -5 to +18 EV |
|---|
Viewfinder and Monitor | Type | Electronic |
|---|
| Resolution | 3,686,000 Dot |
|---|
| Eye Point | 21 mm |
|---|
| Coverage | 100% |
|---|
| Magnification | Approx. 0.76x |
|---|
| Diopter Adjustment | -4 to +3 |
|---|
| Size | 3.2" |
|---|
| Resolution | 1,620,000 Dot |
|---|
| Display | Touchscreen LCD |
|---|
Flash | Built-In | - |
|---|
| Modes | Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction |
|---|
| Max. Sync Speed | 1/250 Second |
|---|
| Compensation | -3 to +3 EV (1/3 EV Steps) |
|---|
| System | TTL |
|---|
| External Connection | Hot Shoe, PC Terminal |
|---|
Interface | Media | Dual Slot: SD/SDHC/SDXC (UHS-II) |
|---|
| Connectivity | 3.5mm Headphone, 3.5mm Microphone, 2.5mm Sub-Mini, HDMI A (Full Size), PC Sync Socket, USB Type-C (USB 3.0) |
|---|
| Wireless | Wi-Fi
Bluetooth |
|---|
| GPS | - |
|---|
Environmental | Temperature | 14 to 104°F / -10 to 40°C |
|---|
| Humidity | 10 to 80% |
|---|
Physical | Battery | 1 x DMW-BLF19 Rechargeable Lithium-Ion, 7.2 VDC, 1860 mAh |
|---|
| WxHxD | 5.5 x 3.9 x 3.4" / 138.5 x 98.1 x 87.4 mm |
|---|
| Weight | 1.45 lb / 660 g (Body with Battery and Memory) |
|---|
Packaging | Weight | 3.03 lb / 1.37 kg |
|---|
| Box LxWxH | 7.75 x 6 x 5.8" |
|---|
|
