Imaging Lens Mount | Micro Four Thirds |
---|
Camera Format | Micro Four Thirds (2x Crop Factor) |
---|
Resolution | Actual: 11.93 Megapixel Effective: 10.28 Megapixel (3680 x 2760) |
---|
Max. Resolution | 3680 x 2760 |
---|
Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
---|
Sensor Type | MOS |
---|
Sensor Size | 17.3 x 13 mm |
---|
Format | JPEG, Raw |
---|
Depth | 14-Bit |
---|
Stabilization | - |
---|
Exposure Control ISO | Auto, 160 to 51200 (Extended: 80 to 204800) |
---|
Shutter | Electronic Front Curtain Shutter 1/8000 to 60 Seconds 1 to 30 Minutes in Bulb Mode 1/16000 to 1/24 Second in Movie Mode Electronic Shutter 1/16000 to 1 Second |
---|
Metering Method | Center-Weighted Average, Multiple, Spot |
---|
Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
---|
Exposure Compensation | -5 to +5 EV (1/3 EV Steps) |
---|
Metering Range | 0 to 18 EV |
---|
White Balance | Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4 |
---|
Continuous Shooting | Up to 12 fps at 10.3 MP for up to 80 Frames (Raw) / 600 Frames (JPEG) Up to 8 fps at 10.3 MP Up to 7 fps at 10.3 MP Up to 6 fps at 10.3 MP Up to 5 fps at 10.3 MP Up to 2 fps at 10.3 MP Up to 60 fps at 8 MP |
---|
Interval Recording | + |
---|
Self-Timer | 2/10-Second Delay |
---|
Video Mode | AVCHD Full HD (1920 x 1080) at 50p/59.94p (28 Mb/s) Full HD (1920 x 1080) at 50i/59.94i (17 to 24 Mb/s) Full HD (1920 x 1080) at 23.976p (24 Mb/s) MP4 4:2:0 10-Bit UHD 4K (3840 x 2160) at 23.976p/25p/29.97p (72 Mb/s) MOV/MP4 4:2:0 8-Bit DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p (100 Mb/s) DCI 4K (4096 x 2160) at 50p/59.94p (150 Mb/s) UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p (100 Mb/s) UHD 4K (3840 x 2160) at 50p/59.94p (150 Mb/s) Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p (100 Mb/s) Full HD (1920 x 1080) at 25p/29.97p (20 Mb/s) Full HD (1920 x 1080) at 23.976p/24.00p (24 Mb/s) Full HD (1920 x 1080) at 50p/59.94p (28 Mb/s) MOV/MP4 4:2:2 10-Bit DCI 4K (4096 x 2160) at 23.976p/24.00p (150 to 400 Mb/s) DCI 4K (4096 x 2160) at 25p/29.97p (150 Mb/s) UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p (150 to 400 Mb/s) Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p (100 to 200 Mb/s) |
---|
External Rec | 4:2:2 10-Bit |
---|
Encoding | NTSC/PAL |
---|
Audio | Built-In Microphone (Stereo) External Microphone Input |
---|
Audio Format | AAC, Dolby Digital 2ch, Linear PCM (Stereo) |
---|
Focus Type | Auto and Manual Focus |
---|
Mode | Continuous-Servo AF (C), Flexible (AFF), Manual Focus (M), Single-Servo AF (S) |
---|
Autofocus Points | Contrast Detection: 225 |
---|
Autofocus Sensitivity | -5 to +18 EV |
---|
Viewfinder and Monitor Type | Electronic |
---|
Resolution | 3,686,000 Dot |
---|
Eye Point | 21 mm |
---|
Coverage | 100% |
---|
Magnification | Approx. 0.76x |
---|
Diopter Adjustment | -4 to +3 |
---|
Size | 3.2" |
---|
Resolution | 1,620,000 Dot |
---|
Display | Touchscreen LCD |
---|
Flash Built-In | - |
---|
Modes | Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction |
---|
Max. Sync Speed | 1/250 Second |
---|
Compensation | -3 to +3 EV (1/3 EV Steps) |
---|
System | TTL |
---|
External Connection | Hot Shoe, PC Terminal |
---|
Interface Media | Dual Slot: SD/SDHC/SDXC (UHS-II) |
---|
Connectivity | 3.5mm Headphone, 3.5mm Microphone, 2.5mm Sub-Mini, HDMI A (Full Size), PC Sync Socket, USB Type-C (USB 3.0) |
---|
Wireless | Wi-Fi Bluetooth |
---|
GPS | - |
---|
Environmental Temperature | 14 to 104°F / -10 to 40°C |
---|
Humidity | 10 to 80% |
---|
Physical Battery | 1 x DMW-BLF19 Rechargeable Lithium-Ion, 7.2 VDC, 1860 mAh |
---|
WxHxD | 5.5 x 3.9 x 3.4" / 138.5 x 98.1 x 87.4 mm |
---|
Weight | 1.45 lb / 660 g (Body with Battery and Memory) |
---|
Packaging Weight | 3.03 lb / 1.37 kg |
---|
Box LxWxH | 7.75 x 6 x 5.8" |
---|
|
