Imaging | Lens Mount | Micro Four Thirds |
|---|
| Resolution | Actual: 21.77 Megapixel
Effective: 20.33 Megapixel |
|---|
| Sensor Type | 17.3 x 13 mm (Four Thirds) MOS |
|---|
| Crop Factor | 2x |
|---|
| Stabilization | Sensor-Shift, 5-Axis |
|---|
| ND Filter | None |
|---|
| Capture Type | Stills & Video |
|---|
Exposure Control | Shutter Type | Mechanical Focal Plane Shutter, Electronic Shutter |
|---|
| Shutter | Electronic Shutter
1/16000 to 60 Seconds
Up to 60 Seconds in Bulb Mode
Electronic Front Curtain Shutter
1/2000 to 60 Seconds
Up to 30 Minutes in Bulb Mode |
|---|
| Bulb | Bulb Mode |
|---|
| ISO | Photo
200 to 25,600 in Auto Mode (Extended: 100 to 25,600)
Video
200 to 12,800 in Auto Mode (Extended: 100 to 12,800) |
|---|
| Metering Method | Center-Weighted Average, Highlight Weighted, Multiple, Spot |
|---|
| Exposure Modes | Aperture Priority, Auto, Manual, Program, Shutter Priority |
|---|
| Exposure Compensation | -5 to +5 EV (1/3 EV Steps) |
|---|
| Metering Range | 0 to 18 EV |
|---|
| White Balance | Presets: Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4 |
|---|
| Continuous Shooting | Up to 12 fps at 20.3 MP
Up to 30 fps at 18 MP
Up to 60 fps at 8 MP |
|---|
| Interval Recording | + |
|---|
| Self-Timer | 2/10-Second Delay |
|---|
Image | Image Sizes | 4:3 Raw
5184 x 3888
4:3 JPEG
5184 x 3888
3712 x 2784
2624 x 1968
3:2 JPEG
5184 x 3456
3712 x 2480
2624 x 1752
16:9 JPEG
5184 x 2920
3840 x 2160
1920 x 1080
1:1 JPEG
3888 x 3888
2784 x 2784
1968 x 1968 |
|---|
| Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
|---|
| Format | JPEG, Raw |
|---|
| Depth | 14-Bit |
|---|
Internal Video | Recording Modes | H.265/MOV 4:2:0 10-Bit
6K Anamorphic (4992 x 3774) at 23.98p/24.00p/25p/29.97p (200 Mb/s)
4K Anamorphic (3328 x 2496) at 50p (200 Mb/s)
DCI 4K (4096 x 2160) at 50p/59.94p (200 Mb/s)
UHD 4K (3840 x 2160) at 50p/59.94p (200 Mb/s)
H.264/MOV 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 23.98p/24.00p/25p/29.97p (150 to 400 Mb/s)
DCI 4K (4096 x 2160) at 50p/59.94p (200 Mb/s)
UHD 4K (3840 x 2160) at 23.98p/24.00p/25p/29.97p (150 to 400 Mb/s)
4K Anamorphic (3328 x 2496) at 23.98p/24.00p/25p/29.97p (150 to 400 Mb/s)
Full HD (1920 x 1080) at 23.98p/24.00p/25p/29.97p/50p/59.94p (100 to 200 Mb/s)
H.264/MOV 4:2:0 8-Bit
4K Anamorphic (3328 x 2496) at 23.98p/24.00p/29.97p/50p/59.94p (100 to 150 Mb/s)
DCI 4K (4096 x 2160) at 23.98p/24.00p/25p/29.97p (100 to 150 Mb/s)
UHD 4K (3840 x 2160) at 23.98p/24.00p/25p/29.97p/50p/59.94p (100 to 150 Mb/s)
Full HD (1920 x 1080) at 23.98p/24.00p/25p/29.97p/50p/59.94p (100 Mb/s)
H.265/MP4 4:2:0 10-Bit
UHD 4K (3840 x 2160) at 23.98p/25p/29.97p/50p/59.94p (72 to 100 Mb/s)
H.264/MP4 4:2:0 8-Bit
UHD 4K (3840 x 2160) at 23.98p/25p/29.97p (100 Mb/s)
Full HD (1920 x 1080) at 23.98p/25p/29.97p/50p/59.94p (20 to 28 Mb/s) |
|---|
| Rec Limit | Unlimited |
|---|
| Video System | NTSC/PAL |
|---|
| Microphone | Stereo |
|---|
| Audio Recording | AAC Audio
LPCM Audio |
|---|
External Video Capture | External Recording | 4:2:2 10-Bit via HDMI |
|---|
| IP Streaming | RTMP: 1280 x 720 to 1920 x 1080 at 25p, 29.97p, 50p, 59.94p (3.0 to 16.00 Mb/s)
RTMPS: 1280 x 720 to 1920 x 1080 at 25p, 29.97p, 50p, 59.94p (3.0 to 8.0 Mb/s) |
|---|
Interface | Media | Dual Slot: SD/SDHC/SDXC (UHS-II) (V90 or Faster Recommended) |
|---|
| Video | 1 x HDMI Output |
|---|
| Audio | 1 x 1/8" / 3.5 mm TRS Stereo Headphone Output
1 x 1/8" / 3.5 mm TRS Stereo Microphone Input |
|---|
| Other | 1 x USB Type-C (USB 3.2 / 3.1 Gen 1) Data Input/Output (Shared with Power Input)
1 x 2.5 mm Sub-Mini Control Input |
|---|
| Power | 1 x USB Type-C Input/Output |
|---|
| Wireless | Bluetooth, Wi-Fi |
|---|
| GPS | None |
|---|
Monitor | Size | 3" |
|---|
| Resolution | 1,840,000 Dot |
|---|
| Display | Free-Angle Tilting Touchscreen LCD |
|---|
Viewfinder | Type | Built-In Electronic (OLED) |
|---|
| Resolution | 3,680,000 Dot |
|---|
| Eye Point | 21 mm |
|---|
| Coverage | 100% |
|---|
| Magnification | Approx. 76x |
|---|
| Diopter Adjustment | -4 to +3 |
|---|
Focus | Type | Auto and Manual Focus |
|---|
| Mode | Automatic, Continuous-Servo AF, Flexible, Manual Focus, Single-Servo AF |
|---|
| Autofocus Points | Contrast Detection: 225 |
|---|
| Autofocus Sensitivity | -4 to +18 EV |
|---|
Flash | Built-In | - |
|---|
| Modes | Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction |
|---|
| Max. Sync Speed | 1/250 Second |
|---|
| Compensation | -3 to +3 EV (1/3 EV Steps) |
|---|
| System | TTL |
|---|
| External Connection | Hot Shoe, PC Terminal |
|---|
Environmental | Temperature | 14 to 104°F / -10 to 40°C |
|---|
| Humidity | 10 to 80% |
|---|
General | Battery | 1 x DMW-BLK22 Rechargeable Lithium-Ion, 7.2 VDC, 2200 mAh (Approx. 400 Shots) |
|---|
| Tripod Mounting | 1 x 1/4"-20 Female (Bottom) |
|---|
| Accessory Mount | 1 x Hot Shoe Mount |
|---|
| Construction | Magnesium Alloy |
|---|
| WxHxD | 5.5 x 3.9 x 3.4" / 138.5 x 98.1 x 87.4 mm |
|---|
| Weight | 1.6 lb / 727 g (Body with Battery and Memory) |
|---|
Packaging | Weight | 2.795 lb / 1.27 kg |
|---|
| Box LxWxH | 7.5 x 6.1 x 5.7" |
|---|
|
