Imaging Lens Mount | Micro Four Thirds |
---|
Resolution | Actual: 26.52 Megapixel Effective: 25.2 Megapixel (5776 x 4336) |
---|
Sensor Type | 17.3 x 13 mm (Four Thirds) MOS |
---|
Crop Factor | 2x |
---|
Stabilization | Sensor-Shift, 5-Axis |
---|
ND Filter | None |
---|
Capture Type | Stills & Video |
---|
Exposure Control Shutter Type | Electronic Shutter |
---|
Shutter | Electronic Front Curtain Shutter 1/2000 to 60 Seconds Up to 30 Minutes in Bulb Mode Electronic Shutter 1/32000 to 1 Second to 60 Seconds in Bulb Mode 1/25,000 to 1/8 Second in Movie Mode |
---|
Bulb | Bulb Mode, Time Mode |
---|
ISO | Photo 100 to 25,600 in Auto Mode (Extended: 50) Video 100 to 12,800 (Extended: 50) |
---|
Metering Method | Center-Weighted Average, Highlight Weighted, Multiple, Spot |
---|
Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
---|
Exposure Compensation | -5 to +5 EV (1/3 EV Steps) |
---|
Metering Range | 0 to 18 EV |
---|
White Balance | Presets: Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4 |
---|
Continuous Shooting | Mechanical Shutter Up to 14 fps for up to 65 Frames (Raw) / 95 Frames (JPEG) Electronic Shutter Up to 75 fps for up to 200 Frames (Raw) / 200 Frames (JPEG) |
---|
Interval Recording | + |
---|
Self-Timer | 2/3/10-Second Delay |
---|
Image Image Sizes | 4:3 JPEG / Raw 25.2 MP (5776 x 4336) 3:2 JPEG / Raw 5776 x 3848 16:9 JPEG / Raw 5776 x 3242 1:1 JPEG / Raw 4336 x 4336 |
---|
Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
---|
Format | JPEG, Raw |
---|
Depth | 14-Bit |
---|
Internal Video Recording Modes | H.264/MOV/MPEG-4 AVC/ProRes 422 HQ 4:2:2 10-Bit 5728 x 3024 at 29.97p (1900 Mb/s) 5728 x 3024 at 23.98p/24.00p (1500 Mb/s) 5728 x 3024 at 25p (1600 Mb/s) H.264/MOV/MPEG-4 AVC/ProRes 422 4:2:2 10-Bit 5728 x 3024 at 29.97p (1300 Mb/s) 5728 x 3024 at 25p (1100 Mb/s) 5728 x 3024 at 23.98p/24.00p (1000 Mb/s) H.264 ALL-Intra/MOV 4:2:2 10-Bit 4096 x 2160 at 47.95p/50p/59.94p (600 to 800 Mb/s) 4096 x 2160 at 23.98p/24.00p/25p/29.97p (400 Mb/s) 3840 x 2160 at 47.95p/50p/59.94p (600 to 800 Mb/s) 3840 x 2160 at 23.98p/24.00p/25p/29.97p (400 Mb/s) 1920 x 1080 at 200p/239.76p (800 Mb/s) 1920 x 1080 at 100p/119.88p (400 Mb/s) 1920 x 1980 at 23.98p/24.00p/25p/29.97p/47.95p/50p/59.94p (200 Mb/s) 1920 x 1080 at 50i/59.94i (100 Mb/s) H.264 Long GOP/MOV/MPEG-4 AVC 4:2:2 10-Bit 4096 x 2160 at 50p/59.94p (200 Mb/s) 4096 x 2160 at 47.95p (200 Mb/s) 4096 x 2160 at 23.98p/24.00p/25p/29.97p (150 Mb/s) 3840 x 2160 at 47.95p/50p/59.94p (200 Mb/s) 3840 x 2160 at 23.98p/24.00p/25p/29.97p (150 Mb/s) 1920 x 1080 at 200p/239.76p (200 Mb/s) 1920 x 1080 at 100p/119.88p (150 Mb/s) 1920 x 1080 at 23.98p/24.00p/25p/29.97p/47.95p/50p/59.94p (100 Mb/s) 1920 x 1080 at 59.94i (50 Mb/s) H.265 Long GOP/MOV 4:2:0 10-Bit 5760 x 4320 at 23.98p/24.00p/25p/29.97p (200 Mb/s) 5728 x 3024 at 47.95p/48.00p/50p/59.94p (300 Mb/s) 5728 x 3024 at 23.98p/24.00p/25p/29.97p (200 Mb/s) 4352 x 3264 at 47.95p/48.00p/50p/59.94p (300 Mb/s) 4096 x 2160 at 100p/119.88p (300 Mb/s) 4096 x 2160 at 47.95p/50p/59.94p (200 Mb/s) 4096 x 2160 at 23.98p/24.00p/25p/29.97p (150 Mb/s) 3840 x 2160 at 100p/119.88p (300 Mb/s) 3840 x 2160 at 47.95p/50p/59.94p (200 Mb/s) 3840 x 2160 at 23.98p/24.00p/25p/29.97p (150 Mb/s) 3840 x 2160 at 23.98p/25p/29.97p/50p/59.94p (100 Mb/s) 3840 x 2160 at 23.98p/25p/29.97p (72 Mb/s) 1920 x 1080 at 200p/239.76p (200 Mb/s) 1920 x 1080 at 100p/119.88p (150 Mb/s) 1920 x 1080 at 23.98p/24.00p/25p/29.97p/47.95p/50p/59.94p (100 Mb/s) 1920 x 1080 at 50p/59.94p (28 Mb/s) 1920 x 1080 at 25p/29.97p (20 Mb/s) 1920 x 1080 at 23.98p (24 Mb/s) |
---|
Variable Frame Rates | 5.7K: to 60 fps DCI 4K: to 119.88 fps 3.8K: to 119.88 fps 1080p: to 300 fps |
---|
Gamma Curve | Panasonic V-Gamut, Panasonic V-Log |
---|
Rec Limit | Unlimited for DCI 4K (4096 x 2160) at 59.94p (4:2:2 10-Bit) |
---|
Video System | NTSC/PAL |
---|
Microphone | Stereo |
---|
Audio Recording | MOV: 2/4-Channel 24-Bit 96 kHz LPCM Audio MOV: 2/4-Channel 24-Bit 48 kHz LPCM Audio MP4: 2-Channel 16-Bit 48 kHz AAC Audio |
---|
External Video Capture External Recording | 4:2:2 10-Bit via HDMI DCI 4K (4096 x 2160) at 50p/59.94p UHD 4K (3840 x 2160) at 50p/59.94p |
---|
IP Streaming | None |
---|
Interface Media | Slot 1: CFexpress Type B Slot 2: SD/SDHC (UHS-II) (U3/V30 or Faster Recommended) |
---|
Video | 1 x HDMI Output |
---|
Audio | 1 x 1/8" / 3.5 mm TRRS Headphone/Mic Microphone Input 1 x 1/8" / 3.5 mm TRRS Headphone/Mic Headphone Output |
---|
Other | 1 x USB Type-C |
---|
Power | 1 x USB Type-C Input/Output |
---|
Wireless | 5 GHz Wi-Fi 5 (802.11ac) Video Output, Audio Output, Control |
---|
GPS | None |
---|
Monitor Size | 3" |
---|
Resolution | 1,840,000 Dot |
---|
Display | Free-Angle Tilting Touchscreen LCD |
---|
Viewfinder Type | Built-In Electronic (OLED) |
---|
Resolution | 3,680,000 Dot |
---|
Eye Point | 21 mm |
---|
Coverage | 100% |
---|
Magnification | Approx. 0.76x |
---|
Diopter Adjustment | -4 to +3 |
---|
Focus Type | Auto and Manual Focus |
---|
Mode | Automatic, Continuous-Servo AF, Focus Lock AF Area Mode, Manual Focus, Single-Servo AF, Touch AF & Shutter |
---|
Autofocus Points | Photo, Video Contrast Detection: 315 |
---|
Autofocus Sensitivity | -4 to +18 EV |
---|
Flash Built-In | - |
---|
Modes | Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction |
---|
Max. Sync Speed | 1/250 Second |
---|
Compensation | -3 to +3 EV (1/3 EV Steps) |
---|
System | TTL |
---|
External Connection | Hot Shoe |
---|
Environmental Temperature | 14 to 104°F / -10 to 40°C |
---|
Storage Humidity | 10 to 80% |
---|
General Battery | 1 x DMW-BLK22 Rechargeable Lithium-Ion, 7.2 VDC, 2200 mAh (Approx. 350 Shots) |
---|
Tripod Mounting | 1 x 1/4"-20 Female |
---|
Accessory Mount | 1 x Hot Shoe Mount |
---|
Construction | Magnesium Alloy |
---|
WxHxD | 5.45 x 3.95 x 3.92" / 13.84 x 10.03 x 9.96 cm |
---|
Weight | 1.8 lb / 823 g (Body with Battery and Memory) 1.63 lb / 739 g (Body Only) |
---|
Packaging Weight | 3.14 lb / 1.42 kg |
---|
Box LxWxH | 7.5 x 6.3 x 6" |
---|
|
