Image | Lens Mount | Micro Four Thirds |
|---|
| Resolution | Actual: 26.52 Megapixel
Effective: 25.2 Megapixel (5776 x 4336) |
|---|
| Sensor Type | 17.3 x 13 mm (Four Thirds) MOS |
|---|
| Crop Factor | 2x |
|---|
| Stabilisation | Sensor-Shift, 5-Axis |
|---|
| ND Filter | None |
|---|
| Capture Type | Stills & Video |
|---|
Exposure | Shutter Type | Electronic Shutter |
|---|
| Bulb/Time Mode | Bulb Mode, Time Mode |
|---|
| ISO Sensitivity | Photo
100 to 25,600 in Auto Mode (Extended: 50)
Video
100 to 12,800 (Extended: 50) |
|---|
| Metering | Center-Weighted Average, Highlight Weighted, Multiple, Spot |
|---|
| Exposure | Aperture Priority, Manual, Program, Shutter Priority |
|---|
| Compensation | -5 to +5 EV (1/3 EV Steps) |
|---|
| Metering Range | 0 to 18 EV |
|---|
| Interval Recording | Yes |
|---|
| Self Timer | 2/3/10-Second Delay |
|---|
Still Photography | Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
|---|
| Format | JPEG, Raw |
|---|
| Bit Depth | 14-Bit |
|---|
Video | Fast, Slow Motion | Yes |
|---|
| Gamma Curve | Panasonic V-Gamut, Panasonic V-Log |
|---|
| Rec Limit | None |
|---|
| Broadcast Output | NTSC/PAL |
|---|
| IP Streaming | None |
|---|
| Built-In Microphone Type | Stereo |
|---|
Connectivity | Video | 1 x HDMI Output |
|---|
| Power | 1 x USB-C Input/Output |
|---|
| Other | 1 x USB-C Data/Monitor/Tether/Video |
|---|
| Wireless | 5 GHz Wi-Fi 5 (802.11ac) Video Output, Audio Output, Control |
|---|
| Satnav (GPS, GLONASS, etc.) | None |
|---|
Screen | Size | 3" |
|---|
| Resolution | 1,840,000 Dot |
|---|
| Screen Type | Free-Angle Tilting Touchscreen LCD |
|---|
Viewfinder | Type | Built-In Electronic (OLED) |
|---|
| Resolution | 3,680,000 Dot |
|---|
| Eye Point | 21 mm |
|---|
| Coverage | 100% |
|---|
| Magnification | Approx. 0.76x |
|---|
| Diopter Adjustment | -4 to +3 |
|---|
Focus | Focusing | Auto and Manual Focus |
|---|
| AF Points | Photo, Video
Contrast Detection: 315 |
|---|
| Autofocus Sensitivity | -4 to +18 EV |
|---|
Flash | Max. Sync Speed | 1/250 Second |
|---|
| Flash Compensation | -3 to +3 EV (1/3 EV Steps) |
|---|
| Dedicated Flash System | TTL |
|---|
| External Connection | Hot Shoe |
|---|
Environmental | Operating Temperature | 14 to 104°F / -10 to 40°C |
|---|
| Storage Humidity | 10 to 80% |
|---|
General Information | Battery Type | 1 x DMW-BLK22 Rechargeable Lithium-Ion, 7.2 VDC, 2200 mAh (Approx. 350 Shots) |
|---|
| Tripod Mounting Thread | 1 x 1/4"-20 Female |
|---|
| Accessory Mount | 1 x Hot Shoe Mount |
|---|
| Material | Magnesium Alloy |
|---|
| WxHxD | 5.45 x 3.95 x 3.92" / 13.84 x 10.03 x 9.96 cm |
|---|
| Weight | 1.8 lb / 823 g (With Battery, Recording Media)
1.63 lb / 739 g (Body Only) |
|---|
Package Information | Package | 3.135 lb / 0.1 kg |
|---|
| Box Dimensions | 8.6 x 6.4 x 6.1" |
|---|
Lens Specifications | Focal | 12 to 60mm (35mm Equivalent Focal Length: 24 to 120mm) |
|---|
| Max Aperture | f/2.8 to 4 |
|---|
| Min Aperture | f/22 |
|---|
| Lens Mount | Micro Four Thirds |
|---|
| Lens Format Coverage | Micro Four Thirds |
|---|
| Angle of View | 84° to 20° |
|---|
| Min. Focus Distance | 7.87" / 20 cm |
|---|
| Max. Magnification | 0.3x |
|---|
| Optical | 14 Elements in 12 Groups |
|---|
| Diaphragm Blades | 9, Rounded |
|---|
| Focus Type | Autofocus |
|---|
| Image Stabilization | Yes |
|---|
| Filter Size | 62 mm (Front) |
|---|
| Dimensions (ø x L) | 2.69 x 3.39" / 68.4 x 86 mm |
|---|
| Length at Max. Extension | 4.72" / 120 mm |
|---|
| Weight | 11.29 oz / 320 g |
|---|
Packaging Info | Package | 1.26 lb / 0.1 kg |
|---|
| Box Dimensions (LxWxH) | 7.1 x 5.4 x 4.5" |
|---|
Battery | Battery Capacity | 2200 mAh / 16 Wh |
|---|
| Chemistry | Lithium-Ion |
|---|
| Output Voltage | 7.2 VDC |
|---|
Packaging Info | Package Weight | 0.23 lb / 0.1 kg |
|---|
| Box Dimensions (LxWxH) | 3.6 x 2.4 x 1.5" |
|---|
|
