Imaging | Lens Mount | Micro Four Thirds |
|---|
| Sensor Type | 17.4 x 13 mm (4/3") MOS |
|---|
| Resolution | Actual: 21.8 Megapixel
Effective: 20.4 Megapixel (5184 x 3888) |
|---|
| Crop Factor | 2x |
|---|
| Aspect Ratio | 4:3 |
|---|
| Format | JPEG, Raw |
|---|
| Depth | 12-Bit |
|---|
| Stabilization | Sensor-Shift, 5-Axis |
|---|
Exposure Control | ISO | Auto, 200 to 25600 (Extended: 64 to 25600) |
|---|
| Shutter | Mechanical Shutter
1/8000 to 60 Seconds
Electronic Shutter
1/32000 to 60 Seconds
1 to 30 Minutes in Bulb Mode |
|---|
| Metering Method | Center-Weighted Average, Multi-Zone, Spot |
|---|
| Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
|---|
| Exposure Compensation | -5 to +5 EV (1/3, 1/2, 1 EV Steps) |
|---|
| Metering Range | -2 to 20 EV |
|---|
| White Balance | Auto, Cloudy, Custom, Daylight, Flash, Fluorescent, Incandescent, Shade, Underwater |
|---|
| Continuous Shooting | Up to 15 fps at 20.4 MP for up to 103 Frames (Raw) / 132 Frames (JPEG)
Up to 10 fps at 20.4 MP for up to 287 Frames (Raw) / Unlimited Frames (JPEG)
Up to 60 fps at 20.4 MP for up to 49 Frames (Raw) / 49 Frames (JPEG)
Up to 18 fps at 20.4 MP for up to 74 Frames (Raw) / 89 Frames (JPEG) |
|---|
| Interval Recording | + |
|---|
| Self-Timer | 2/12-Second Delay |
|---|
Video | Recording Modes | H.264/MOV
DCI 4K (4096 x 2160) at 24.00p (237 Mb/s)
UHD 4K (3840 x 2160) at 23.976p/25p/29.97p (102 Mb/s)
Full HD (1920 x 1080) at 23.976p/25p/29.97p/50p/59.94p (18 to 200 Mb/s)
HD (1280 x 720) at 23.976p/25p/29.97p/50p/59.94p (10 to 102 Mb/s) |
|---|
| External Recording | 4:2:2 8-Bit
DCI 4K (4096 x 2160)UHD 4K (3840 x 2160)Full HD (1920 x 1080)HD (1280 x 720) |
|---|
| Rec Limit | Up to 29 Minutes |
|---|
| Video Encoding | NTSC/PAL |
|---|
| Audio Recording | Built-In Microphone (Stereo)
External Microphone Input |
|---|
| Audio File Format | Linear PCM (Stereo) |
|---|
Focus | Type | Auto and Manual Focus |
|---|
| Mode | Continuous-Servo AF (C), Manual Focus (M), Single-Servo AF (S) |
|---|
| Autofocus Points | Phase Detection: 121 (121 Cross-Type)
Contrast Detection: 121 |
|---|
Viewfinder | Viewfinder Type | Electronic |
|---|
| Viewfinder Resolution | 2,360,000 Dot |
|---|
| Viewfinder Eye Point | 21 mm |
|---|
| Viewfinder Coverage | 100% |
|---|
| Viewfinder Magnification | Approx. 0.83x |
|---|
| Diopter Adjustment | -4 to +2 |
|---|
Monitor | Size | 3.0" |
|---|
| Resolution | 1,037,000 Dot |
|---|
| Display | Touchscreen LCD |
|---|
Flash | Built-In | - |
|---|
| Modes | Fill Flash, Manual, Off, Red-Eye Reduction, Second-Curtain Sync, Slow Sync, Slow Sync/Red-Eye Reduction |
|---|
| Max. Sync Speed | 1/250 Second |
|---|
| Compensation | -3 to +3 EV (1/3, 1/2, 1 EV Steps) |
|---|
| System | TTL |
|---|
| External Connection | Hot Shoe, PC Terminal |
|---|
Interface | Media | Dual Slot: SD/SDHC/SDXC (UHS-II) |
|---|
| Connectivity | 3.5mm Headphone, 3.5mm Microphone, 2.5mm Sub-Mini, HDMI D (Micro), PC Sync Socket, USB Type-C (USB 3.0) |
|---|
| Wireless | Wi-Fi
Bluetooth |
|---|
| GPS | + |
|---|
Environmental | Temperature | 14 to 104°F / -10 to 40°C |
|---|
| Humidity | 30 to 90% |
|---|
| Storage Temperature | -4 to 140°F / -20 to 60°C |
|---|
| Storage Humidity | 10 to 90% |
|---|
Physical | Battery | 2 x BLH-1 Rechargeable Lithium-Ion, 7.4 VDC, 1720 mAh |
|---|
| WxHxD | 5.7 x 5.8 x 3" / 144.4 x 146.8 x 75.4 mm |
|---|
| Weight | 2.19 lb / 997 g (Body with Battery and Memory) |
|---|
Packaging | Weight | 4.575 lb / 2.08 kg |
|---|
| Box LxWxH | 10 x 7.8 x 5.65" |
|---|
|
