| Lens Mount | Micro Four Thirds |
|---|
| Sensor Type | 17.3 x 13 mm (4/3") MOS |
|---|
| Resolution | Actual: 21.77 Megapixel
Effective: 20.3 Megapixel (5184 x 3888) |
|---|
| Crop Factor | 2x |
|---|
| Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
|---|
| Format | JPEG, Raw |
|---|
| Stabilization | Sensor-Shift, 5-Axis |
|---|
Imaging | ISO | Auto, 200 to 25600 (Extended: 100 to 25600) |
|---|
| Shutter | Electronic Front Curtain Shutter
1/8000 to 60 Seconds
1 to 30 Minutes in Bulb Mode
1/16000 to 1/24 Second in Movie Mode
Electronic Shutter
1/16000 to 1 Second |
|---|
| Metering Method | Center-Weighted Average, Multiple, Spot |
|---|
| Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
|---|
| Exposure Compensation | -5 to +5 EV (1/3 EV Steps) |
|---|
| Metering Range | 0 to 18 EV |
|---|
| White Balance | Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4 |
|---|
| Continuous Shooting | Up to 12 fps at 20.3 MP
Up to 30 fps at 18 MP
Up to 60 fps at 8 MP |
|---|
| Interval Recording | + |
|---|
| Self-Timer | 2/10-Second Delay |
|---|
Exposure Control | Recording Modes | MOV/MP4 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 23.976p/24.00p (150 to 400 Mb/s)
UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p (150 to 400 Mb/s)
Full HD (1920 x 1080) at 50p/59.94p (100 to 200 Mb/s)
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p (100 to 200 Mb/s)
MOV/MP4 4:2:0 8-Bit
DCI 4K (4096 x 2160) at 23.976p/24.00p (100 Mb/s)
UHD 4K (3840 x 2160) at 50p/59.94p (150 Mb/s)
UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p (100 Mb/s)
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p/180p (100 Mb/s)
Full HD (1920 x 1080) at 50p/59.94p (28 Mb/s)
Full HD (1920 x 1080) at 25p/29.97p (20 Mb/s)
Full HD (1920 x 1080) at 23.976p/24.00p (24 Mb/s)
MP4 4:2:0 10-Bit
UHD 4K (3840 x 2160) at 23.976p/25p/29.97p (72 Mb/s)
AVCHD
Full HD (1920 x 1080) at 50p/59.94p (28 Mb/s)
Full HD (1920 x 1080) at 50i/59.94i (17 to 24 Mb/s)
Full HD (1920 x 1080) at 23.976p (24 Mb/s) |
|---|
| External Recording | 4:2:2 10-Bit |
|---|
| Video Encoding | NTSC/PAL |
|---|
| Audio Recording | Built-In Microphone (Stereo)
External Microphone Input |
|---|
| Audio File Format | AAC, Dolby Digital 2ch |
|---|
Video | Type | Auto and Manual Focus |
|---|
| Mode | Continuous-Servo AF (C), Flexible (AFF), Manual Focus (M), Single-Servo AF (S) |
|---|
| Autofocus Points | Contrast Detection: 225 |
|---|
| Autofocus Sensitivity | -4 to +18 EV |
|---|
Focus | Viewfinder Type | Electronic |
|---|
| Viewfinder Resolution | 3,686,000 Dot |
|---|
| Viewfinder Eye Point | 21 mm |
|---|
| Viewfinder Coverage | 100% |
|---|
| Viewfinder Magnification | Approx. 0.76x |
|---|
| Diopter Adjustment | -4 to +3 |
|---|
Viewfinder | Size | 3.2" |
|---|
| Resolution | 1,620,000 Dot |
|---|
| Display | Touchscreen LCD |
|---|
Monitor | Built-In | - |
|---|
| Modes | Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction |
|---|
| Max. Sync Speed | 1/250 Second |
|---|
| Compensation | -3 to +3 EV (1/3 EV Steps) |
|---|
| System | TTL |
|---|
| External Connection | Hot Shoe, PC Terminal |
|---|
Flash | Media | Dual Slot: SD/SDHC/SDXC (UHS-II) |
|---|
| Connectivity | 3.5mm Headphone, 3.5mm Microphone, 2.5mm Sub-Mini, HDMI A (Full Size), USB Type-C (USB 3.0) |
|---|
| Wireless | Wi-Fi
Bluetooth |
|---|
| GPS | - |
|---|
Interface | Temperature | 14 to 104°F / -10 to 40°C |
|---|
| Humidity | 10 to 80% |
|---|
Environmental | Battery | 1 x DMW-BLF19 Rechargeable Lithium-Ion, 7.2 VDC, 1860 mAh |
|---|
| WxHxD | 5.5 x 3.9 x 3.4" / 138.5 x 98.1 x 87.4 mm |
|---|
| Weight | 1.59 lb / 725 g (Body with Battery and Memory) |
|---|
Physical | Weight | 3.315 lb / 0.49 kg |
|---|
| Box LxWxH | 7.65 x 6.1 x 5.8" |
|---|
Packaging | Focal | 12 to 35mm (35mm Equivalent Focal Length: 24 to 70mm) |
|---|
| Max Aperture | f/2.8 |
|---|
| Min Aperture | f/22 |
|---|
| Lens Mount | Micro Four Thirds |
|---|
| Format Compatibility | Micro Four Thirds |
|---|
| Angle of View | 84° to 34° |
|---|
| Min. Focus Distance | 9.84" / 25 cm |
|---|
| Max. Magnification | 0.17x |
|---|
| Optical | 14 Elements in 9 Groups |
|---|
| Diaphragm Blades | 7, Rounded |
|---|
| Focus Type | Autofocus |
|---|
| Image Stabilization | + |
|---|
| Filter Size | 58 mm (Front) |
|---|
| Dimensions (ø x L) | 2.66 x 2.91" / 67.6 x 73.8 mm |
|---|
| Weight | 10.76 oz / 305 g |
|---|
Info | Package | 1.09 lb / 0.49 kg |
|---|
| Box Dimensions | 6.45 x 4.55 x 4.5" |
|---|
|
